PERFORMANCE DATA (cont)
ELECTRIC HEATING CAPACITIES
*Two heater packages required to provide kW indicated.
†On units with factory-installed outlet, use CRSINGLE014A00.
NOTES:
The kW ratings shown above are at 240 and 480 v. Use the Multiplication
Factors table to determine heater capacity for your particular voltage.
MULTIPLICATION FACTORS
EXAMPLE: 32.0 kW (at 240 v) heater on 208 v
= 32.0 (.75 mult factor)
= 24.0 kW capacity at 208 v.
UNIT
548F
VO LTAG E
(60 Hz)
ACCESSORY
kW
ACCESSORY
HEATER
PART NUMBER
CRHEATER---A00
ACCESSORY
SINGLE
POINT BOX
PART N O.
CRSINGLE---A00
036
208/230
(single phase)
4.4 101 —
6.5 102 —
8.7 103 —
10.5 104 —
13.0* 102* 004
208/230
(3 phase)
4.4 101 —
6.5 102 —
8.7 103 —
10.5 104 —
16.0 105 —
460
(3 phase)
6.0 106 —
8.8 107 —
11.5 108 —
14.0 109 —
048
208/230
(single phase)
4.4 101 —
8.7 103 —
13.0* 102* 004
17.4* 103* 004
21.0* 104* 004
208/230
(3 phase)
6.5 102 —
8.7 103 —
16.0 105 —
21.0* 104* 002
460
(3 phase)
6.0 106 —
11.5 108 —
14.0 109 —
23.0* 108* —
060
208/230
(single phase)
6.5 102 —
8.7 103 —
13.0* 102* 004
17.4* 103* 004
21.0* 104* 004
208/230
(3 phase)
6.5 102 —
10.5 104 —
16.0 105 —
21.0* 104* 002
26.5* 105,104 002
460
(3 phase)
6.0 106 —
11.5 108 —
14.0 109 —
23.0* 108* —
25.5* 109,108 —
UNIT
548F
VO LTAG E
(60 Hz)
ACCESSORY
kW
ACCESSORY
HEATER
PART NUMBER
CRHEATER---A00
ACCESSORY
SINGLE
POINT BOX
PART N O.
CRSINGLE---A00
072
208/230
(3 phase)
6.5 102 —
10.5 104 —
16.0 105 —
21.0* 104* 002
26.5* 105,104 002
460
(3 phase)
6.0 106 —
11.5 108 —
14.0 109 —
23.0* 108* —
25.5* 109,108 —
090,102
208/230
(3 phase)
10.4 117 006
16.0 110 006
24.8 111 007
32.0 112 007
42.4* 112,117 009
460
(3 phase)
13.9 116 006
16.5 113 006
27.8 114 006
33.0 115 006
41.7* 114,116 008
120
208/230
(3 phase)
10.4 117 012
16.0 110 012
32.0 112 012
42.4* 112,117 015
50.0* 112,110 015
460
(3 phase)
16.5 113 011
27.8 114 011
33.0 115 011†
41.7* 114,116 014
50.0* 115,113 014
HEATER RATING
VOLTAGE
VOLTAGE
DISTRIBUTION
V-3-60
MULTIPLICATION
FACTOR
240
200 0.69
208 0.75
230 0.92
240 1.00
480
440 0.84
460 0.92
480 1.00
575
545 0.90
575 1.00
600 1.09
50TFQ004-012
548F036-120
