ELECTRICAL DATA
UNITS WITHOUT ELECTRICAL CONVENIENCE OUTLET
UNIT
549B
NOMINAL
VOLTAGE
(V-Ph-Hz)
VOLTAGE
RANGE
COMPRESSOR OFM IFM
ELECTRIC
HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP FLA LRA
036
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—
/—
—
/—
25.6/ 25.6 30/ 30** 25/ 25 101/101
3.3/ 4.4 15.9/18.3 45.5/ 48.5 50/ 50** 43/ 46 117/120
4.9/ 6.5 23.6/27.1 55.1/ 59.5 60/ 60** 52/ 56 125/128
6.5/ 8.7 31.3/36.3 64.7/ 71.0 70/ 80 61/ 67 133/138
7.9/10.5 38.0/43.8 73.1/ 80.4 80/ 90 69/ 75 139/145
9.8/13.0 47.1/54.2 84.5/ 93.4 90/100 79/ 87 148/155††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—
/—
—
/—
18.5/ 18.5 20/ 20** 18/ 18 90/ 90
3.3/ 4.4 9.2/10.6 30.0/ 31.7 30/ 35** 29/ 30 99/101
4.9/ 6.5 13.6/15.6 35.5/ 38.0 40/ 40** 34/ 36 104/106
6.5/ 8.7 18.0/20.9 41.0/ 44.6 45/ 45** 39/ 42 108/111
7.9/10.5 21.9/25.3 45.9/ 50.1 50/ 60** 43/ 47 112/116
12.0/16.0 33.3/38.5 60.1/ 66.6 70/ 70 57/ 63 124/129
460-3-60 414 508 5.1 39.0 0.4 2.2
—— 9.0 15** 9 46
6.0 7.2 18.0 20** 17 53
8.8 10.6 22.2 25** 21 57
11.5 13.8 26.2 30** 25 60
14.0 16.8 30.0 30** 28 63
048
(4 Tons)
208/230-1-60 187 254 23.7 129.0 0.7 4.9
—
/—
—
/—
35.2/ 35.2 40/ 40** 34/ 34 142/142
3.3/ 4.4 15.9/18.3 55.1/ 58.1 60/ 60** 52/ 55 158/161
6.5/ 8.7 31.3/36.3 74.4/ 80.6 80/ 90 70/ 75 174/179
9.8/13.0 47.1/54.2 94.1/103.0 100/110 88/ 96 189/196††
13.1/17.4 63.0/72.5 114.0/125.9 125/150 106/117 205/215††
15.8/21.0 76.0/87.5 130.2/144.6 150/150 121/134 218/230††
208/230-3-60 187 254 13.5 99.0 0.7 4.9
—
/—
—
/—
22.5/ 22.5 25/ 25** 22/ 22 112/112
4.9/ 6.5 13.6/15.6 39.5/ 42.0 40/ 45** 38/ 40 126/128
6.5/ 8.7 18.0/20.9 45.0/ 48.6 45/ 50** 43/ 46 130/133
12.0/16.0 33.3/38.5 64.1/ 70.6 70/ 80 60/ 66 146/151
15.8/21.0 43.9/50.5 77.4/ 85.6 90/100 72/ 80 156/163
460-3-60 414 508 7.4 49.5 0.4 2.2
—— 11.9 15** 12 57
6.0 7.2 20.9 25** 20 64
11.5 13.8 29.1 30** 27 70
14.0 16.8 32.9 35** 31 73
23.0 27.7 46.5 50** 43 84
060
(5 Tons)
208/230-1-60 187 254 28.8 169.0 1.5 8.8
—
/—
—
/—
46.3/ 46.3 50/ 50** 45/ 45 216/216
4.9/ 6.5 23.6/27.1 75.8/ 80.2 80/ 90 72/ 76 240/243
6.5/ 8.7 31.3/36.3 85.4/ 91.7 90/100 81/ 87 247/252††
9.8/13.0 47.1/54.2 105.2/114.1 110/125 99/107 263/270††
13.1/17.4 63.0/72.5 125.1/136.9 150/150 117/128 279/289††
15.8/21.0 76.0/87.5 141.3/155.7 150/175 132/146 292/304††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—
/—
—
/—
28.9/ 28.9 30/ 30** 28/ 28 168/168
4.9/ 6.5 13.6/15.6 45.9/ 48.4 50/ 50** 44/ 46
181/183
7.9/10.5 21.9/25.3 56.3/ 60.6 60/ 70 53/ 57
190/193
12.0/16.0 33.3/38.5 70.6/ 77.1 80/ 80 67/ 73
201/208
15.8/21.0 43.9/50.5 83.8/ 92.1 90/100 79/ 86
212/218††
19.9/26.5 55.2/63.8 97.9/108.7 100/110 92/102
223/232††
460-3-60 414 508 9.0 62.0 0.8 2.6
—— 14.7 15** 14 84
6.0 7.2 23.7 25** 23 92
11.5 13.8 31.9 35** 30 98
14.0 16.8 35.7 40** 34 101
23.0 27.7 49.3 50** 46 112
25.5 30.7 53.0 60** 50 115
072
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 5.8
—
/—
—
/—
32.8/ 32.8
35/ 35**
32/ 32 200/200
4.9/ 6.5 13.6/15.6 49.8/ 52.3 50/ 60** 47/ 50 214/216
7.9/10.5 21.9/25.3 60.2/ 64.5 70/ 70 57/ 61 222/225
12.0/16.0 33.3/38.5 74.5/ 81.0 80/ 90 70/ 76 233/239
15.8/21.0 43.9/50.5 87.7/ 96.0 90/100 82/ 90 244/251††
19.9/26.5 55.2/63.8 101.8/112.6 110/125 95/105 255/264††
460-3-60 414 508 9.6 70.0 0.6 2.6
—— 15.2 20** 15 92
6.0 7.2 24.2 25** 23 99
11.5 13.8 32.5 35** 31 106
14.0 16.8 36.2 40** 34 109
23.0 27.7 49.8 50** 47 120
25.5 30.7 53.6 60** 50 123
