ELECTRICAL DATA (cont)
UNITS WITH ELECTRICAL CONVENIENCE OUTLET
UNIT
549B
NOMINAL
VOLTAGE
(V-Ph-Hz)
VOLTAGE
RANGE
COMPRESSOR OFM IFM
ELECTRIC
HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP FLA LRA
036
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—
/—
—
/—
30.4/ 30.4 35/ 35** 30/ 30 106/106
3.3/ 4.4 15.9/18.3 50.3/ 53.3 60/ 60** 49/ 51 122/124
4.9/ 6.5 23.6/27.1 59.9/ 64.3 60/ 70 58/ 62 130/133
6.5/ 8.7 31.3/36.3 69.5/ 75.8 70/ 80 66/ 72 137/142
7.9/10.5 38.0/43.8 77.9/ 85.2 80/ 90 74/ 81 144/150††
9.8/13.0 47.1/54.2 89.3/ 98.2 90/100 85/ 93 153/160††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—
/—
—
/—
23.3/ 23.3 25/ 25** 24/ 24 95/ 95
3.3/ 4.4 9.2/10.6 34.8/ 36.5 35/ 40** 34/ 36 104/106
4.9/ 6.5 13.6/15.6 40.3/ 42.8 45/ 45** 39/ 42 109/111
6.5/ 8.7 18.0/20.9 45.8/ 49.4 50/ 50** 45/ 48 113/116
7.9/10.5 21.9/25.3 50.7/ 54.9 60/ 60** 49/ 53 117/120
12.0/16.0 33.3/38.5 64.9/ 71.4 70/ 80 62/ 68 128/134
460-3-60 414 508 5.1 39.0 0.4 2.2
——11.2 15** 11 48
6.0 7.2 20.2 25** 20 55
8.8 10.6 24.4 25** 24 59
11.5 13.8 28.4 30** 27 62
14.0 16.8 32.2 35** 31 65
048
(4 Tons)
208/230-1-60 187 254 23.7 129.0 0.7 4.9
—
/—
—
/—
40.0/ 40.0 45/ 45** 39/ 39 147/147
3.3/ 4.4 15.9/18.3 59.9/ 62.9 60/ 70 58/ 60 163/165
6.5/ 8.7 31.3/36.3 79.2/ 85.4 80/ 90 75/ 81 178/183††
9.8/13.0 47.1/54.2 98.9/107.8 100/110 93/102 194/201††
13.1/17.4 63.0/72.5 118.8/130.7 125/150 112/123 210/220††
15.8/21.0 76.0/87.5 135.0/149.4 150/150 127/140 223/235††
208/230-3-60 187 254 13.5 99.0 0.7 4.9
—
/—
—
/—
27.3/ 27.3 30/ 30** 27/ 27 117/117
4.9/ 6.5 13.6/15.6 44.3/ 46.8 45/ 50** 43/ 45 131/133
6.5/ 8.7 18.0/20.9 49.8/ 53.4 50/ 60** 48/ 52 135/138
12.0/16.0 33.3/38.5 68.9/ 75.4 70/ 80 66/ 72 150/156
15.8/21.0 43.9/50.5 82.2/ 90.4 90/100 78/ 86 161/168††
460-3-60 414 508 7.4 49.5 0.4 2.2
——14.0 15** 14 59
6.0 7.2 23.0 25** 22 66
11.5 13.8 31.3 35** 30 73
14.0 16.8 35.0 40** 33 76
23.0 27.7 48.7 50** 46 86
060
(5 Tons)
208/230-1-60 187 254 28.8 169.0 1.5 8.8
—
/—
—
/—
51.1/ 51.1 60/ 60** 50/ 50 221/221
4.9/ 6.5 23.6/27.1 80.6/ 85.0 90/ 90 78/ 82 245/248††
6.5/ 8.7 31.3/36.3 90.2/ 96.5 100/100 86/ 92 252/257††
9.8/13.0 47.1/54.2 110.0/118.9 110/125 105/113 268/275††
13.1/17.4 63.0/72.5 129.9/141.7 150/150 123/134 284/293††
15.8/21.0 76.0/87.5 146.1/160.5 150/175 138/151 297/308††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—
/—
—
/—
33.7/ 33.7 35/ 35** 34/ 34 173/173
4.9/ 6.5 13.6/15.6 50.7/ 53.2 60/ 60** 49/ 52 186/188
7.9/10.5 21.9/25.3 61.1/ 65.4 70/ 70 59/ 63 194/198
12.0/16.0 33.3/38.5 75.4/ 81.9 80/ 90 72/ 78 206/211
15.8/21.0 43.9/50.5 88.6/ 96.9 90/100 84/ 92 216/223††
19.9/26.5 55.2/63.8 102.7/113.5 110/125 97/107 228/236††
460-3-60 414 508 9.0 62.0 0.8 2.6
——16.8 20** 17 87
6.0 7.2 25.8 30** 25 94
11.5 13.8 34.1 35** 33 100
14.0 16.8 37.8 40** 36 103
23.0 27.7 51.5 60** 49 114
25.5 30.7 55.2 60** 52 117
072
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 5.8
—
/—
—
/—
37.6/ 37.6 40/ 40** 37/ 37 205/205
4.9/ 6.5 13.6/15.6 54.6/ 57.1 60/ 60** 53/ 55 219/221
7.9/10.5 21.9/25.3 65.0/ 69.3 70/ 70 63/ 66 227/230
12.0/16.0 33.3/38.5 79.3/ 85.8 80/ 90 76/ 82 238/243††
15.8/21.0 43.9/50.5 92.5/100.8 100/110 88/ 95 249/255††
19.9/26.5 55.2/63.8 106.6/117.4 110/125 101/111 260/269††
460-3-60 414 508 9.6 70.0 0.6 2.6
——17.4 20** 17 94
6.0 7.2 26.4 30** 26 101
11.5 13.8 34.6 35** 33 108
14.0 16.8 38.4 40** 37 111
23.0 27.7 52.0 60** 49 122
25.5 30.7 55.8 60** 53 125
50TFQ004-012
549B036-120
