Dry Coil Air Delivery -- Downflow Discharge
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
574D--- --- A30060
25 - 55
o
F
(14 - 31
o
C)
Low Blue
CFM 756 669 548 457 --- --- --- --- --- ---
WATTS 84 90 96 106 --- --- --- --- --- ---
BHP 0.09 0.10 0.10 0.11 --- --- --- --- --- ---
Heating
Rise (
o
F)
40 45 55 NA --- --- --- --- --- ---
Heating
Rise (
o
C)
22 25 31 NA --- --- --- --- --- ---
Med-Low Pink
CFM 1002 928 842 733 660 560 450 --- --- ---
WATTS 144 155 161 173 185 192 203 --- --- ---
BHP 0.15 0.17 0.17 0.19 0.20 0.21 0.22 --- --- ---
Heating
Rise (
o
F)
30 33 36 41 46 54 NA --- --- ---
Heating
Rise (
o
C)
17 18 20 23 25 30 NA --- --- ---
Medium
2
Red
CFM 1110 1025 967 879 814 706 611 509 461 ---
WATTS 188 195 205 211 223 236 243 255 243 ---
BHP 0.20 0.21 0.22 0.23 0.24 0.25 0.26 0.27 0.26 ---
Heating
Rise (
o
F)
27 29 31 34 37 43 49 59 NA ---
Heating
Rise (
o
C)
15 16 17 19 21 24 27 33 NA ---
Med-High
1
Orange
CFM 1160 1091 1004 945 866 804 699 615 496 ---
WATTS 213 225 232 243 249 261 273 285 291 ---
BHP 0.23 0.24 0.25 0.26 0.27 0.28 0.29 0.31 0.31 ---
Heating
Rise (
o
F)
NA NA 30 32 35 38 43 49 NA ---
Heating
Rise (
o
C)
NA NA 17 18 19 21 24 27 NA ---
High Black
CFM 1240 1173 1110 1031 966 902 821 726 626 ---
WATTS 254 266 274 284 295 302 315 327 331 ---
BHP 0.27 0.29 0.29 0.30 0.32 0.32 0.34 0.35 0.35 ---
Heating
Rise (
o
F)
NA NA NA NA 31 34 37 42 48 ---
Heating
Rise (
o
C)
NA NA NA NA 17 19 20 23 27 ---
