Dry Coil Air Delivery -- Downflow Discharge
UNIT
HEATING RISE
RANGE
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
574D--- --- A36060
25 - 55
o
F
(14 - 31
o
C)
Low Blue
CFM 1277 1215 1147 1094 1045 992 932 874 826 757
WATTS 285 289 299 305 314 319 328 335 347 352
BHP 0.31 0.31 0.32 0.33 0.34 0.34 0.35 0.36 0.37 0.38
Heating
Rise (
o
F)
NA 25 26 28 29 30 32 35 37 40
Heating
Rise (
o
C)
NA 14 15 15 16 17 18 19 20 22
Med-Low Pink
CFM 1312 1260 1203 1153 1095 1050 995 943 889 829
WATTS 314 324 329 340 344 355 361 372 382 387
BHP 0.34 0.35 0.35 0.36 0.37 0.38 0.39 0.40 0.41 0.42
Heating
Rise (
o
F)
NA NA 25 26 28 29 30 32 34 36
Heating
Rise (
o
C)
NA NA 14 15 15 16 17 18 19 20
Medium
2
Red
CFM 1381 1326 1269 1212 1161 1121 1070 1019 974 912
WATTS 358 365 375 383 391 395 406 418 424 434
BHP 0.38 0.39 0.40 0.41 0.42 0.42 0.44 0.45 0.45 0.47
Heating
Rise (
o
F)
NA NA NA 25 26 27 28 30 31 33
Heating
Rise (
o
C)
NA NA NA 14 14 15 16 16 17 18
Med-High
1
Orange
CFM 1631 1579 1525 1477 1423 1372 1336 1284 1233 1166
WATTS 567 576 581 592 598 609 617 619 613 598
BHP 0.61 0.62 0.62 0.63 0.64 0.65 0.66 0.66 0.66 0.64
Heating
Rise (
o
F)
NA NA NA NA NA NA NA NA 25 26
Heating
Rise (
o
C)
NA NA NA NA NA NA NA NA 14 14
High Black
CFM 1681 1633 1575 1526 1478 1415 1366 1312 1249 1159
WATTS 618 626 636 644 652 653 649 642 627 602
BHP 0.66 0.67 0.68 0.69 0.70 0.70 0.70 0.69 0.67 0.65
Heating
Rise (
o
F)
NA NA NA NA NA NA NA NA NA 26
Heating
Rise (
o
C)
NA NA NA NA NA NA NA NA NA 14
