MODEL NUMBER NOMENCLATURE
583B N W 024 040 A A A D
Indoor Motor - Horse
Power (Not an option)
D
– 1/4 Direct Drive
F
– 1/2 Direct Drive
G
– 3/4 Direct Drive and Aba
Model Number
583B – Single Package
Gas Heating/
Electric Cooling
Electrical Supply
N
– 208/230-1-60
P
– 208/230-3-60
E
– 460-3-60
Series
A
– Original
Fuel and Controls
W
– Natural Gas
P
– Propane Gas
Low No
x
Indicator
A
– Std. Unit
N
– Low No
x
Unit
Nominal Cooling Capacity
024
– 2.0 Tons
030
– 2.5 Tons
036
– 3.0 Tons
042
– 3.5 Tons
048
– 4.0 Tons
060
– 5.0 Tons
Heat Input Size (Btuh)
040
– 40,000
060
– 60,000
090
– 90,000
115
– 115,000
130
– 130,000
ARI* CAPACITIES
COOLING CAPACITIES AND EFFICIENCIES
UNIT 583B NOMINAL TONS STANDARD CFM
NET COOLING
CAPACITIES (Btuh)
SEER†
SOUND RATINGS**
(dB)
024040
024060
2 800 24,000 12.0 7.2
030040
036060
2-1/2 1000 29,000 12.0 7.2
036060
036090
3 1200 35,000 12.0 7.2
042060
042090
3-1/2 1400 41,000 12.0 7.3
048090
048115
048130
4 1600 48,000 12.0 7.8
060090
060115
060130
5 1750 59,000 12.0 7.6
LEGEND
dB
— Decibels
db
— Dry Bulb
SEER
— Seasonal Energy Efficiency Ratio
wb
— Wet Bulb
* Air Conditioning & Refrigeration Institute.
† Rated in accordance with U.S. Government DOE (Department of
Energy) test procedures and/or ARI Standard 210/240-89.
** Tested in accordance with ARI Standard 270-95 (not listed in ARI).
NOTES:
1. Ratings are net values, reflecting the effects of circulating fan heat.
Ratings are based on:
Cooling Standard:
80°F db, 67°F wb indoor entering-air tempera-
ture and 95°F db outdoor entering-air temperature.
2. Before purchasing this appliance, read important energy cost and
efficiency information available from your retailer.
Options
A
– Louvered Grille
J
– Louvered Grille, AL Evaporator
and Vinyl-Coated Condenser
Coil Fin
L
– Louvered Grille, AL Evaporator
and CU Condenser Coil
M
– Louvered Grille, CU Evaporator
and CU Condenser Coils
LEGEND
CU
— Copper
AL
— Aluminum
