PHYSICAL DATA
UNIT SIZE 583B 024040 024060 030040 030060 036060 036090 042060 042090
NOMINAL CAPACITY (ton)
2 2 2-1/2 2-1/2 3 3 3-1/2 3-1/2
OPERATING WEIGHT (lb) 290 290 313 313 321 321 382 382
COMPRESSORS Scroll
Quantity 1
REFRIGERANT (R-410A)
Quantity (lb)
5.0 5.0 5.5 5.5 6.9 6.9 9.0 9.0
REFRIGERANT METERING DEVICE
Orifice ID (in.) AccuRater® Piston
.057 .057 .057 .057 .065 .065 .070 .070
CONDENSER COIL
Rows—Fins/in.
Face Area (sq ft)
1/17
10.9
1/17
10.9
1/17
12.7
1/17
12.7
2/17
9.1
2/17
9.1
2/17
12.3
2/17
12.3
CONDENSER FAN
Nominal Cfm
Diameter (in.)
Motor Hp (Rpm)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
EVAPORATOR COIL
Rows—fins/in.
Face Area (sq ft)
3/15
3.7
3/15
3.7
3/15
3.7
3/15
3.7
3/15
3.7
3/15
3.7
3/15
4.7
3/15
4.7
EVAPORATOR BLOWER
Nominal Airflow (Cfm)
Size (in.)
Motor (Hp)
800
10 x 10
1/4
800
10 x 10
1/4
800
10 x 10
1/4
1000
10 x 10
1/4
1200
10 x 10
1/2
1200
10 x 10
1/2
1400
11 x 10
3/4
1400
11 x 10
3/4
FURNACE SECTION
Burner Orifice No. (Qty…Drill Size)
Natural
Burner Orifice No. (Qty…Drill Size)
Propane
2…44
2…50
2…38
2…46
2…44
2…50
2…38
2…46
2…38
2…46
3…38
3…46
2…38
2…46
3…38
3…46
HIGH-PRESSURE SWITCH (psig)
Cutout
Reset (Auto.)
610 ± 15
420 ± 25
LOSS-OF-CHARGE/LOW-PRESSURE SWITCH
(Liquid Line) (psig)
Cutout
Reset (Auto.)
20 ± 5
45 ± 10
RETURN-AIR FILTERS (in.)
Throwaway
20 x 24 x 1 20 x 24 x 1 20 x 24 x 1 20 x 24 x 1 20 x 24 x 1 20 x 24 x 1 24 x 30 x 1 24 x 30 x 1
