—3—
000 A A AA
Standard Unit
Series
A
– Original Series
B
– Second Series
Common Unit
– U.S.A. Only
Heating Size
RECOMMENDED TUBE DIAMETERS
NOTES:
1.Tube diameters are for lengths up to 50 ft. For tubing lengths greater than 50 ft horizontal and/or 20 ft vertical differential, consult the Application
Guideline and Service Manual for Residential Split-System Air Conditioners and Heat Pumps using Puron Refrigerant.
2. Refrigerant tubes and indoor coils must be evacuated to 500 microns to minimize contamination and moisture in the system.
METERING DEVICE
* TXV must be installed when indoor coil is not equipped with a Puron approved TXV. TXV listed is for any approved coil combination. All TXVs are Puron spe-
cific bi-flow hard shutoff.
A-WTD. SOUND POWER (dBA)
Note: Tested in accordance with ARI Standard 270-95. (Not listed with ARI).
UNIT
SIZE
LIQUID TUBE
DIAMETER (IN.) VAPOR TUBE DIAMETER (IN.)
0 to 50 Ft
Tube Length
0 to 50 Ft
Tube Length
0 to 50 Ft
Alternate
024 3/8 5/8 3/4 ACR
030 3/8 3/4 5/8, 7/8
036 3/8 3/4 5/8, 7/8
042, 048 3/8 7/8 3/4, 7/8
060 3/8 1-1/8 7/8
UNIT SIZE SERIES OUTDOOR PISTON INDOOR TXV*
REQUIRED SUBCOOLING
(°F)
024 D, E 46 KSATX0201PUR 11
030 D, E 52 KSATX0201PUR 9
036 D, E 57 KSATX0301PUR 14
042 D, E 59 KSATX0301PUR 11
048 D, E, F 63 KSATX0401PUR 10
060 D, E 73 KSATX0501PUR 12
UNIT SIZE
SERIES
STANDARD
RATING
TYPICAL OCTAVE BAND SPECTRUM (without tone adjustment)
125 250 500 1000 2000 4000 8000
024-D, E 71 53.0 58.0 62.0 63.5 63.0 56.0 49.0
030-D, E 73 54.0 62.0 64.0 65.0 63.5 60.0 53.0
036-D, E 74 59.5 65.0 67.5 68.0 65.5 61.5 53.5
042-D, E 74 58.0 64.5 67.5 67.0 65.0 60.5 52.5
048-D, E, F 77 60.0 67.5 69.5 68.5 65.0 63.0 55.0
060-D, E 77 59.0 67.5 69.0 70.0 67.5 65.0 59.0
MODEL NUMBER NOMENCLATURE
650A N X 024
Model Number
13 SEER Split-System
Heat Pump
N/A
Electrical Supply
N
– 208/230-1-60
Nominal Cooling Capacity
024
– 2 ton
042
– 3.5 ton
030
– 2.5 ton
048
– 4 ton
036
– 3 ton
060
– 5 ton
