Bryant 650A - Balance Point Worksheet; Heating Capacity Analysis Tool

—16—
BUILDING HEAT LOSS, 1000 BTU/HR
UNIT INTEGRATED HEATING CAPACITY, 1000 BTU/HR
Printed in U.S.A.
OUTDOOR TEMPERATURE, F
-10
0
10 20
30 40
50 60 70
80
2.9 5.9 8.8 11.7 14.7 17.6 20.5
70 60 50 40 30 20 10
kW
BASED ON INDOOR ENT. AIR AT
70
F AND AT RATED CFM
23.4
80
650AN BALANCE POINT WORKSHEET
650AN024-E FX4A030
650AN030-E FX4A030
650AN036-E FX4A042
650AN042-E FV4A003
650AN048-E, F FV4A005
650AN060-E FV4A006
A05005
