—15—
* Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included. Ratings are based on:
Cooling Standard: 80°F (27°C) db 67°F (19°C) wb indoor entering air temperature and 95°F (35°C) db air entering outdoor unit.
High-Temp Heating Standard: 70°F (21°C) db indoor entering air temperature and 47°F (8°C) db 43°F (6°C) wb air entering outdoor unit.
Low-Temp Heating Standard: 70°F (21°C) db indoor entering air temperature and 17°F (–9°C) db 15°F (–10°C) wb air entering outdoor unit.
† Outdoor section/indoor section combination tested in accordance with DOE test procedure for heat pumps.
‡ Based on computer simulation. TXV must be Puron compatible and hard shutoff type.
** In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance.
Use either the accessory Time-Delay Relay KAATD0101TDR or a furnace equipped with TDR.
†† Indoor Airflow
‡‡ Must replace Factory-supplied R-22 TXV with Puron TXV.
COP — Coefficient of Performance TC— Total Capacity (Btuh)
EER — Energy Efficiency Ratio TDR— Time-Delay Relay
HSPF — Heating Seasonal Performance Factor TXV— Thermostatic Expansion Valve
SEER — Seasonal Energy Efficiency Ratio
048-D,
E, F
CK5A/CK5BT060 45,000 TDR — — 12.50 — 10.90 47,500 3.44 28,200 2.36 8.1
CK5A/CK5BX060 45,000 TDR — — 12.70 — 11.10 47,500 3.48 28,200 2.38 8.1
CK5PA060 45,000 TDR&TXV 12.50 — — — 10.90 47,500 3.44 28,200 2.36 8.1
CK5PT060 45,000 TDR&TXV 12.50 — — — 10.90 47,500 3.44 28,200 2.36 8.1
CK5PX060 45,000 TDR&TXV 12.70 — — — 11.10 47,500 3.48 28,200 2.38 8.1
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 43,000 TDR — 13.00 — — 11.05 46,500 3.18 27,600 2.28 7.5
CC5A/CD5AW048 43,000 TDR — 13.00 — — 11.00 47,000 3.22 27,600 2.28 7.5
CD5PX060 44,500 TDR&TXV 13.50 — — — 11.40 48,000 3.54 28,400 2.40 8.0
CK3BA060 45,000 TDR — — 13.00 — 11.30 47,000 3.52 27,800 2.40 8.2
CK5A/CK5BA060 45,000 TDR — — 13.00 — 11.25 47,000 3.50 27,800 2.40 8.2
CK5A/CK5BT060 45,000 TDR — — 13.00 — 11.25 47,000 3.50 27,800 2.40 8.2
CK5A/CK5BX060 45,500 TDR — — 13.50 — 11.45 47,500 3.54 27,800 2.44 8.3
CK5PA060 45,000 TDR&TXV 13.00 — — — 11.25 47,000 3.50 27,800 2.40 8.2
CK5PT060 45,000 TDR&TXV 13.00 — — — 11.25 47,000 3.50 27,800 2.40 8.2
CK5PX060 45,500 TDR&TXV 13.50 — — — 11.45 47,500 3.54 27,800 2.44 8.3
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CC5A/CD5AA060 43,000 TDR — 13.00 — — 11.05 46,500 3.18 27,400 2.28 7.5
CC5A/CD5AW048 43,000 TDR — 13.00 — — 11.05 47,000 3.22 27,400 2.30 7.5
CK5A/CK5BA060 45,000 TDR — — 13.00 — 11.30 47,000 3.52 27,800 2.40 8.2
CK5A/CK5BT060 45,000 TDR — — 13.00 — 11.30 47,000 3.52 27,800 2.40 8.2
CK5A/CK5BX060 45,500 TDR — — 13.50 — 11.45 47,500 3.54 27,800 2.44 8.3
CK5PA060 45,000 TDR&TXV 13.00 — — — 11.30 47,000 3.52 27,800 2.40 8.2
CK5PT060 45,000 TDR&TXV 13.00 — — — 11.30 47,000 3.52 27,800 2.40 8.2
CK5PX060 45,500 TDR&TXV 13.50 — — — 11.45 47,500 3.54 27,800 2.44 8.3
060-D, E
*FV4BNB006 58,000 TDR&TXV 13.00 — — — 10.75 60,000 3.56 37,000 2.54 8.1
CC5A/CD5AW060 56,000 NONE — — 12.50 — 10.45 58,500 3.26 36,800 2.42 7.6
CD5PX060 56,500 TXV — — — 12.00 10.25 60,000 3.46 37,600 2.48 8.0
CK5A/CK5BX060 56,500 NONE — — 12.50 — 10.55 59,000 3.44 37,000 2.50 7.8
CK5PX060 56,500 TXV — — — 12.50 10.55 59,000 3.44 37,000 2.50 7.8
FB4BNB070 57,000 TDR — 12.20 — — 10.20 60,000 3.44 37,800 2.46 7.8
FC4CNB070 57,000 TDR&TXV — 12.20 — — 10.20 60,000 3.44 37,800 2.46 7.8
FE4ANB006 58,000 TDR&TXV 13.00 — — — 10.75 60,000 3.56 37,000 2.54 8.1
FK4DNB006 58,000 TDR&TXV — 13.00 — — 10.75 59,500 3.56 37,000 2.54 8.0
FX4BNB060 57,000 TDR&TXV 12.10 — — — 10.20 60,000 3.44 37,800 2.46 7.8
COILS + 315(A,J)AV066110 VARIABLE-SPEED FURNACE
CD5PX060 56,500 TDR&TXV 12.50 — — — 10.50 59,000 3.52 37,200 2.52 8.0
COILS + 315(A,J)AV066155 VARIABLE-SPEED FURNACE
CC5A/CD5AW060 56,000 TDR — 12.50 — — 10.55 58,500 3.28 36,600 2.44 7.6
COILS + 355MAV060080 VARIABLE-SPEED FURNACE
CD5PX060 55,500 TDR&TXV 12.00 — — — 9.90 60,000 3.36 37,800 2.42 7.5
COILS + 355MAV060100 VARIABLE-SPEED FURNACE
CD5PX060 56,000 TDR&TXV 12.00 — — — 10.05 60,000 3.40 37,600 2.44 7.5
COILS + 355MAV060120 VARIABLE-SPEED FURNACE
CD5PX060 55,000 TDR&TXV 12.00 — — — 10.15 61,000 3.40 37,400 2.44 7.5
UNIT
SIZE-
SERIES
INDOOR
UNIT CFM††
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency SEER
EER
High-Temp Low-Temp
HSPF
Factory-
Supplied
Enhance-
ment
Standard
Rating
Field-Supplied
Accessory‡
Puron
TXV
Puron
TXV
& TDR**
TC COP TC COP
COMBINATION RATINGS continued
