Bryant 650A - Product Specifications; Electrical and Compressor Details

—4—
SPECIFICATIONS
See notes on page 5.
UNIT SIZE-SERIES 024-D, E 030-D, E 036-D, E
Operating Weight (Lb) 214 205 216
ELECTRICAL
Unit Volts—Hertz—Phase 208/230—60—1
Operating Voltage Range* 187—253
Compressor Rated Load Amps 15.1 14.7 19.3
Compressor Locked Rotor Amps 61.0 72.5 83.0
Condenser Fan Motor—Full Load Amps 0.8 1.1 1.1
Minimum Unit Ampacity for Wire Sizing 19.7 19.5 25.2
Minimum Wire Size (60°C Copper) (AWG)† 14 14 12
Minimum Wire Size (75°C Copper) (AWG)† 14 14 12
Maximum Wire Length (60°C) (Ft)‡ 39 39 50
Maximum Wire Length (75°C) (Ft)‡ 37 37 48
Maximum Branch Circuit Fuse Size** 30 30 35
COMPRESSOR & REFRIGERANT
Compressor Type Scroll
Refrigerant Type Puron
Refrigerant Amount (Lb)†† 7.18 6.63 8.375
OUTDOOR COIL & FAN
Coil Face Area (Sq Ft) 18.18 15.15 18.18
Fins per In.—Rows—Circuits 25—1—2 25—1—3 25—1—4
Fan Motor—HP & RPM 1/8 and 825 1/5 and 825 1/5 and 825
Rated Airflow (CFM) 2400 2800 2800
OPTIONAL EQUIPMENT
Support Feet—4 In. (4) KSASF0101AAA
Snow Stand—18 In. KHASS0206MPK
Time Delay Relay KAATD0101TDR
Ball-Bearing Fan Motor HC38GE231 (RCD)
MotorMaster®—Low-Ambient Controller‡‡ KSALA0401AAA
Outdoor Thermostat KHAOT0301FST
Secondary Outdoor Thermostat KHAOT0201SEC
Crankcase Heater KAACH1201AAA
Start Assist—Capacitor/Relay Type KSAHS1501AAA
Start Assist—PTC Type Standard KAACS0201PTC
Bi-Flow TXV (Hard Shutoff) KSATX0201PUR KSATX0301PUR
Evaporator Freeze Thermostat*** KAAFT0101AAA
Isolation Relay*** KHAIR0101AAA
Liquid-Line Solenoid Valve (LSV) KHALS0401LLS
Low-Ambient Pressure Switch KSALA0301410
Coastal Filter KAACF0801MED
Pressure Guard™ Kit KHAPG0101PGS KHAPG0201PGS
Evolution Controls See chart.
As an ENERGY STAR®
partner, Bryant Heating &
Cooling Systems has
determined that this prod-
uct meets the ENERGY
STAR® guidelines for
energy efficiency.
CERTIFICATION APPLIES ONLY
WHEN THE COMPLETE SYSTEM
IS LISTED WITH ARI.
*
M
A
N
U
F
A
C
T
U
R
E
R
C
E
R
T
I
F
I
E
D
T
O
A
R
I
A
S
C
O
M
P
L
Y
I
N
G
W
I
T
H
A
R
I
S
T
A
N
D
A
R
D
2
4
0
U
N
I
T
A
R
Y
H
E
A
T
P
U
M
P
E
Q
U
I
P
M
E
N
T
®
*Refer to the combination ratings in the Product Data Sheet for system combinations that meet Energy Star® efficiency standards.
