C. Section 3 — Selecting Electric Heater
If the indoor unit is a fan coil and the electric heater is not
self-identifying, ″ELECTRIC HEATER NOT IDENTIFIED″ will
appear (See figure 17). Press either Time or Temp +/- buttons to
select appropriate size of electric heater installed, then press the
right-side button to continue.
NOTE: Range of electric heaters available is limited by the model
of the fan coil installed. The Evolution Control™ will not allow an
electric heater size that is not supported by the installed fan coil.
D. Section 4 — Selecting Accessories
Once the indoor and outdoor equipment have been found or
entered, the following screens will appear allowing the Installer to
select the AIR FILTER TYPE; HUMIDIFIER INSTALLED; and
UV LIGHTS INSTALLED″ (See Fig. 18). Use either Time or
Temp +/- buttons to make the appropriate selections in the
highlighted area on the display screen. Press right-side button to
continue (or advance) to the next screen.
AIR FILTER TYPE— This accessory screen will appear first.
The installer will need to enter the type of filter (MEDIA, EAC, or
both). See Table 1 and make a selection using Time or Temp +/-
button, then press right-side button to continue.
HUMIDIFIER TYPE — This will appear after the Air Filter
Type screen. Select whether a humidifier is installed on the
system, YES or NO, then press the right-side button to continue.
UV LIGHTS INSTALLED— This screen will appear to select
whether UV lights are installed on the system, select YES or NO,
then press the right side button to continue.
E. Section 5 — Equipment Summary
The ″EQUIPMENT SUMMARY″ screen will appear after Ac-
cessories have been selected. This screen will give a summary of
all equipment automatically found or manually selected. If a wrong
selection was made, press left-side button (BACK selection) to go
back to that particular screen and make changes. When everything
is OK, press right-side button again to continue. (See figure 19)
The ″SETUP COMPLETE! SAVE ALL SELECTIONS?″
screen will appear after Equipment Summary. To Save All
Selections press (YES) right-side button. Pressing the left-side
button (NO selection) will return to the Equipment Summary
screen where you can back up to any of the equipment selection
screens and perform changes. After selecting YES, the initial
power up sequence of the new Evolution Control™ is complete.
The User Interface screen will now display normal operating
mode. Also, after selecting YES, if the filter type is not an EAC,
the indoor unit will operate the blower for one minute to do a
system static pressure check.
QUICK START
For first time installers, Quick Start will allow you to start up the
Evolution System before you have the chance to learn all the
details of system operation. However, for the best possible comfort
and operation we recommend that you refer to the Evolution
Control™ Homeowner’s Guide.
A. Set Day, Time & Desired Humidity
1. Flip down the door at the base of the Evolution Control™
and press the BASIC button.
2. Adjust the highlighted HOUR setting using the TIME
(+/−) button.
3. Press SCROLL button (down) to highlight MINUTE.
4. Adjust the MINUTE setting using the TIME (+/−) button.
5. Press SCROLL button (down) to highlight DAY.
6. Adjust the current DAY setting using the TIME (+/−)
button.
7. Press SCROLL button (down) to highlight HUMIDITY.
8. Press the red HEAT button to select heating humidity.
9. Adjust desired heating humidity level using either (+/−)
button.
10. Press the blue COOL button to select cooling humidity.
11. Adjust the desired cooling humidity level using
either(+/−)button.
12. To exit press BASIC button or close door.
B. Override Heating Schedule
1. Press the red HEAT button. Heating mode is confirmed
when the red LED next to the red HEAT button is lit.
2. Use the TEMP (+/−) button to select your desired heating
temperature.
3. The default time for temporarily overriding the temperature
schedule is 2:00 HRS as indicated by the text on the lower
left.
NOTE: Override time will not appear if programming has been
turned off.
4. You can change the temporarily override time in 15-minute
increments by pressing the TIME (+/−) button until the
desired override time is selected, or press the HOLD button
anytime to override the schedule indefinitely.
Fig. 17—Selecting Electric Heater
A03197
ELECTRIC HEATER
NOT IDENTIFIED
ENTER SIZE: 5 KW
NONE, 5,10,15 KW
PRESS +/- TO MAKE
SELECTION
BACK CONTINUE
INSTALLED FILTER MENU SELECTION
1 Inch to 4 inch media MEDIA
High voltage EAC EAC
High voltage EAC+1to4inch media MEDIA + EAC
Table 1 — Filter Selection
Fig. 18—Accessories — UV Lights
A03198
ACCESSORIES
HUMIDIFIER
INSTALLED? YES
PRESS +/- TO MAKE
SELECTION
BACK CONTINUE
ACCESSORIES
U.V. LIGHTS
INSTALLED? YES
PRESS +/- TO MAKE
SELECTION
BACK CONTINUE
ACCESSORIES
AIR FILTER TYPE:
EAC EAC
MEDIA
MEDIA + EAC
PRESS +/- TO MAKE
SELECTION
CONTINUE
AIR FILTER MEDIA TYPE HUMIDIFIER INSTALLED? U.V. LIGHTS INSTALLED?
Fig. 19—Equipment Summary
A04034
EQUIPMENT SUMMARY
FURNACE 355MAV0420
AC 598BNX024
FILTER EAC
HUMIDIFIER YES
UV LIGHTS YES
BACK EXIT
SETUP
COMPLETE!
SAVE
ALL SELECTIONS?
NO YES
—6—
