SETUP = HEAT PUMP / AC:
COOLING LOCKOUT:
• NONE (default)
• 45° F.
• 50° F.
• 55° F.
Outside temperature below which cooling will not be provided.
ENTERED SIZE:
• (dependent on indoor unit model)
Size of the outdoor unit entered during the start-up process. If the
outdoor unit is a communicating model, this value will not be
shown. This size can be changed here but is limited to sizes that the
indoor unit can handle.
DEFROST INTERVAL:
• 30 minutes
• 60 minutes
• 90 minutes (default)
• 120 minutes
Time interval at which defrost cycles can occur on a heat pump.
ELECT HEAT LOCKOUT:
• NONE (default)
• +5 to 55 deg. F
Outside temperature above which the electric heat will not operate.
HIGH COOL LATCH:
• NONE (default)
• 80 - 110 deg F
Outside temperature above which only the high speed (of a
2-speed outdoor unit) will run when cooling.
A. Setup = ACCESSORIES
FILTER TYPE:
• MEDIA
• EAC
• MEDIA+EAC
CLEAN INTERVAL: 30 to 180 days (of blower operation).
(Default = 90)
Interval at which the Clean Filter notification will turn on. Applies
to EAC or MEDIA+EAC filter selection only.
B. Setup = Humidifier
HUMIDIFIER INSTALLED:
• NO
• YES
If YES, indicates to the system whether a humidifier is installed
and enables humidification functions.
CHANGE PAD INTERVAL: 1 to 24 months of humidifier
operation (default=6 months)
Interval at which the Change Humidify Pad notification will be
displayed.
HUMIDIFY WITH FAN:
• NO (default)
• YES
If YES, the humidifier will run with Continuous Fan if there is a
humidify demand.
SETUP = VENTILATOR
NOTE: Only appears if ventilator is installed.
CLEAN INTERVAL:
• 60 to 180 days of operation (default=90)
Interval at which the Clean Ventilator Pre-filter notification will
turn on.
SETUP = UV LIGHTS
UV LIGHTS INSTALLED:
• NO
• YES
If YES, indicates to the system whether UV lights are installed.
CHANGE INTERVAL:
• 6 to 48 months operation time (default=12 months)
Interval at which the Change UV Lights notification will be
displayed.
SETUP = SYSTEM MAINTENANCE
REMIND OWNER OF ROUTINE MAINTENANCE EVERY:
This setup is used to adjust the timer interval in which the normal
System Maintenance notification is turned on for the homeowner.
• Range= OFF, 6 to 24 months, (default=12)
CHECKOUT MENUS
The Checkout menu will show the equipment installed in the
system. A sample checkout menu is shown in Fig. 24.
Checkout = FURNACE
Make sure the furnace is properly installed before continuing.
• LOW HEAT RUNTIME: 5 min.
• HIGH HEAT RUNTIME: 5 min.
This menu item allows the furnace to be exercised. First, a low
heat runtime and high heat runtime are selected.
If only the low heat is to be exercised:
The furnace will execute its ignition start-up sequence. This
sequence will be displayed on the Evolution Control screen. After
the gas valve and blower motor turn on, the screen will automati-
cally change to show the current operating status of the furnace.
Checkout = FAN COIL
ELECTRIC HEAT CHECK
• ELECTRIC HEAT RUNTIME: 5 min., Default time = 5 min.,
Range=0-120min.
If you have a fan coil with electric heaters, this menu item will
allow the heaters to be exercised.
With self-identifying electric heaters, three stages of electric heat
are available to be exercised in any combination. Non-identifying
heaters will only provide one stage of heat.
Enter the run time (in minutes) of each stage of heat to be
exercised then press START (right-side button). The display will
change to show the fan coil’s operating status.
Fig. 24 — CHECKOUT MENUS
A03204
CHECKOUT
FURNACE
HEAT PUMP HEATING
HEAT PUMP COOLING
HUMIDIFIER
VENTILATOR
BACK SELECT
—9—
To Next Page
