PERFORMANCE DATA
569J*07A CONDENSER ONLY RATINGS
SST (_F)
AIR TEMPERATURE ENTERING CONDENSER (_ F)
80 85 95 100 105 115
20
TC 46.7 45.1 41.7 39.8 37.9 33.9
kW 4.04 4.27 4.77 5.04 5.32 5.93
SDT 91.6 96.4 105.9 110.6 115.3 124.7
25
TC 51.8 50.2 46.5 44.6 42.6 38.4
kW 4.06 4.29 4.79 5.05 5.33 5.95
SDT 92.7 97.5 106.9 111.6 116.3 125.6
30
TC 57.0 55.2 51.4 49.4 47.3 42.9
kW 4.07 4.30 4.80 5.07 5.35 5.96
SDT 93.9 98.6 108.1 112.7 117.4 126.7
35
TC 62.7 60.8 56.8 54.6 52.4 47.8
kW 4.09 4.32 4.81 5.08 5.36 5.98
SDT 95.1 99.8 109.2 113.9 118.6 127.8
40
TC 68.7 66.7 62.5 60.2 57.9 53.0
kW 4.11 4.34 4.83 5.10 5.38 5.99
SDT 96.5 101.1 110.5 115.1 119.7 128.8
45
TC 75.2 73.1 68.5 66.2 63.7 58.6
kW 4.13 4.36 4.84 5.10 5.38 5.99
SDT 97.9 102.5 111.8 116.3 120.9 129.9
50
TC 82.2 79.9 75.1 72.5 69.9 64.4
kW 4.15 4.37 4.85 5.12 5.39 6.00
SDT 99.4 104.0 113.1 117.6 122.2 131.1
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 13.1
569J*08A CONDENSER ONLY RATINGS
SST (_F)
AIR TEMPERATURE ENTERING CONDENSER (_ F)
80 85 95 100 105 115
20
TC 65.2 63.2 59.1 57.0 54.8 50.5
kW 5.04 5.33 5.98 6.34 6.73 7.60
SDT 95.3 100.2 109.8 114.7 119.5 129.2
25
TC 71.5 69.4 65.0 62.8 60.5 55.9
kW 5.12 5.42 6.07 6.42 6.81 7.66
SDT 96.4 101.2 110.8 115.6 120.4 129.9
30
TC 77.8 75.5 70.9 68.5 66.2 61.3
kW 5.22 5.51 6.16 6.51 6.89 7.74
SDT 97.6 102.4 111.9 116.6 121.3 130.7
35
TC 84.8 82.4 77.5 75.0 72.4 67.2
kW 5.32 5.61 6.26 6.61 6.99 7.83
SDT 98.8 103.5 112.9 117.6 122.3 131.6
40
TC 92.3 89.7 84.5 81.8 79.0 73.5
kW 5.44 5.73 6.37 6.72 7.10 7.94
SDT 100.1 104.8 114.2 118.8 123.5 132.7
45
TC 100.3 97.5 91.9 89.0 86.1 80.1
kW 5.57 5.86 6.50 6.85 7.23 8.07
SDT 101.6 106.2 115.5 120.2 124.8 133.9
50
TC 108.7 105.8 99.8 96.7 93.6 87.3
kW 5.71 6.00 6.64 7.00 7.38 8.21
SDT 103.1 107.8 117.0 121.6 126.2 135.3
NOTE:
Condensing unit only ratings are at 45
_FSSTand95_F entering ---air temperature. EER = 13.0
LEGEND:
k W --- C o m p r e s s o r P o w e r
SDT --- Saturated Discharge Temperature at Compressor (
_F)
SST --- Saturated Suction Temperature (
_F)
TC --- Gross Cooling Capacity (1000 Btuh)
