Bryant LEGACY 569J - Model Number Nomenclature; Model Type; Voltage; Nominal Tonnage

4
MODEL NUMBER NOMENCLATURE
1234567891011121314151617
5 6 9 J E 1 4 A 0 0 0 G 0 0 A 0 A
_____________
Model Type
569J = Bryant Condensing Unit
Puronr R--- 410A Refrigerant
Voltage Packaging
E = 460/3/60 A=Standard
P = 208/230/3/60 B=LTL
T = 575/3/60
Base Unit Controls
Nominal Tonnage 0=None
07 = 6 Tons 16 = 15 Tons
08 = 7.5 Tons 25 = 20 Tons Electrical Options
12 = 10 Tons A=None
14 = 12.5 Tons C = Non---Fused Disconnect
Refrigerant Circuit Service Options
A = Single Circuit 0 = Electro--- Mechanical Controls
B = Single Circuit with Low Ambient Controller 1 = Unpowered Convenience Outlet
D=DualCircuit 2 = Powered Convenience Outlet
E = Dual Circuit with Low Ambient controller
Factory Assigned
Factory Assigned 0=Default
0=Default
Coil Options --- Condenser
With All Aluminum --- NOVATION Design
(07---16 sizes)
Factory Assigned G=Al/Al
0=Default K = E --- C o a t A l / A l
T=Al/Alwithlouveredhailguard
W = E---Coat Al/Al with louvered hail guard
Coil Options --- Condenser
With Round Tube/Plate Fin Design
A=Al/CuStandard
B = P r e --- C o a t e d A l / C u
C --- E --- C o a t A l / C u
E= Cu/Cu
M=Al/CuStandardwithlouveredhailguard
N=Pre---CoatedAl/Cuwithlouveredhailguard
P = E---Coat al/Cu with louvered hail guard
R = Cu/Cu --- Louvered hail gu ard
Factory Assigned
0=Default
