5
AHRI* CAPACITY RATINGS
UNIT
COOLING
CIRCUITS
COMPRESSORS
NOM.
CAPACITY
(TONS)
NET COOLING
CAPACITY
(MBH)
TOTAL
POWER
(kW)
EER IEER
569J*07A/524J*07 1 1 6 71.0 6.2 11.5 12.2
569J*08A/524J*08 1 1 7.5 92.0 8.2 11.2 11.8
569J*12A/524J*12 1 1 10 117.0 10.4 11.2 12.0
569J*14A/524J*14 1 1 12.5 148.0 13.5 11.0 12.0
569J*16A/524J*16 1* 2 15 184.0 16.4 11.2 13.2
569J*25A/524J25 1* 2 20 240.0 21.8 11.0 11.2
* Single circuit with two (tandem) compressors. See application tip #38TIP --- 10---03 for staging capabilities.
UNIT
COOLING
CIRCUITS
COMPRESSORS
NOM.
CAPACITY
(TONS)
NET COOLING
CAPACITY
(MBH)
TOTAL
POWER
(kW)
EER IEER
569J*12D/524J12 2 2 10 117.0 10.4 11.2 11.6
569J*14D/524J14 2 2 12.5 148.0 13.5 11.0 12.0
569J*16D/524J16 2 2 15 184.0 16.4 11.2 11.8
569J*25D/524J25 2 2 20 240.0 21.8 11.0 11.2
LEGEND
AHRI --- Air Conditioning, Heating and Refrigeration
Institute
ASHRAE --- American Society of Heating, Refrigerating
and Air Conditioning, Inc.
EER --- Energy Efficiency Ratio
IEER --- Integrated Energy Efficiency Ratio
NOTES
1. Rated in accordance with AHRI Standard 340/360, as
appropriate.
2. Ratings are based on:
Cooling Standard: 80_F(27_C) db, 67_F(19_C) wb
indoor air temp and 95_F(35_C) db outdoor air temp.
IEER Standard: 80_F(27_C) db, 67_F(19_C) wb indoor
air temp and 4 various outdoor temperatures.
3. All units comply with ASHRAE 90.1 Energy Standard for
minimum EER and IEER requirements.
SOUND POWER LEVELS, dB
UNIT
COOLING
CIRCUITS
OUTDOOR SOUND (dB)
A --- W E I G H T E D 63 125 250 500 1000 2000 4000 8000
N O V A T I O N --- A l l A l u m i n u m C o i l D e s i g n
569J*07A 1 82 86.4 86.0 79.2 80.2 77.6 72.0 67.9 62.3
569J*08A 1 82 86.8 85.7 80.3 80.3 77.7 72.3 70.2 65.4
569J*12A 1 82 82.8 81.5 79.2 79.4 76.2 72.3 69.4 64.2
569J*14A 1 82 82.9 78.5 77.0 77.0 75.6 75.9 72.3 70.9
569J*16A 1 80 90.3 81.8 78.0 76.7 75.2 70.5 66.4 61.9
569J*25A 1 85 91.0 85.0 80.0 86.0 79.0 73.0 68.0 63.0
569J*12D 2 82 85.2 84.0 81.0 79.5 76.6 72.4 69.3 69.5
569J*14D 2 82 84.7 79.8 78.8 77.6 77.0 72.5 70.3 67.3
569J*16D 2 80 90.3 81.8 78.0 76.7 75.2 70.5 66.4 61.9
569J*25D 2 85 91.0 85.0 80.0 86.0 79.0 73.0 68.0 63.0
RTPF --- Round Tube/Plate Fin Coil Design
569J*07A 1 85 89.3 85.0 82.0 82.7 80.2 75.2 71.0 66.0
569J*08A 1 85 89.3 85.0 82.0 82.7 80.2 75.2 71.0 66.0
569J*12A 1 83 86.6 81.9 85.7 80.0 77.1 74.6 69.2 65.8
569J*12D 2 84 86.3 85.8 81.4 81.9 79.5 75.1 71.9 68.9
569J*14D 2 83 81.7 80.9 82.2 80.4 78.2 73.6 69.7 65.4
569J*16A 2 83 86.7 81.2 78.9 80.4 78.0 74.2 70.2 65.0
569J*16D 2 83 86.7 81.2 78.9 80.4 78.0 74.2 70.2 65.0
569J*25A 2 85 91.0 85.0 80.0 86.0 79.0 73.0 68.0 63.0
569J*25D 2 85 91.0 85.0 80.0 86.0 79.0 73.0 68.0 63.0
LEGEND
dB = Decibel
NOTE: Outdoor sound data is measure in accordance with AHRI standard 270 ---2008.
