PHYSICAL DATA
Single Circuit Models with NOVA TION --- All Aluminum Coil Design
569J*07A 569J*08A 569J*12A 569J*14A 569J*16A
Refrigeration System
# Circuits / # Comp. / Type 1/1/Scroll 1/1/Scroll 1/1/Scroll 1/1/Scroll 1/2/Scroll
R ---410A charge A/B (lbs) 4.4 4.9 6.3 7.3 12.2
System charge w/ fan coil 8.4 10.2 13.8 18.0 24.6
Metering device TXV TXV TXV TXV TXV
High ---press. Trip / Reset (psig) 630 / 505 630 / 505 630 / 505 630 / 505 630 / 505
Low ---press. Trip / Reset (psig) 54 / 117 54 / 117 54 / 117 54 / 117 54 / 117
Cond. Coil
Material (Fin/Tube) Al/Al Al/Al Al/Al Al/Al Al/Al
Coil type Novation Novation Novation Novation Novation
Rows / FPI 1/20.3 1/20.3 1/20.3 1/20.3 1/20.3
Tota l fa ce a re a (f t2 ) 17.5 20.5 25.0 31.8 25.0 x 2
Cond. fan / motor
Qty / Motor drive type 2/direct 2/direct 2/direct 2/direct 3/direct
Motor HP / RPM 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100
Fan diameter (in) 22 22 22 22 22
Nominal A irflow (cfm) 6,000 6,000 6,000 6,000 10,000
Watts (total) 610 610 610 610 970
Note: 569J*25 model is not available with NOVATION coil.
Single Circuit Models with RTPF --- Round Tube/Plate Fin Coil Design
569J*07A 569J*08A 569J*12A 569J*14A 569J*16A 569J*25A
Refrigeration System
# Circuits / # Comp. / Type 1/1/Scroll 1/1/Scroll 1/1/Scroll 1/1/Scroll 1/2/Scroll 1/2/Scroll
R ---410a charge A/B (lbs) 11.0 13.0 16.0 32.0 32.0 28.0
System charge w/ fan coil* 14.0 17.0 20.0 N/A 43.0 38.0
Metering device TXV TXV TXV TXV TXV TXV
High ---press. Trip / Reset (psig) 630 / 505 630 / 505 630 / 505 630 / 505 630 / 505 630 / 505
Low ---press. Trip / Reset (psig) 54 / 117 54 / 117 54 / 117 54 / 117 54 / 117 54 / 117
Cond. Coil
Material (Fin/Tube) Al/Cu Al/Cu Al/Cu Al/Cu Al/Cu Al/Cu
Coil type RTPF RTPF RTPF RTPF RTPF RTPF
Rows / FPI 2/17 2/17 2/17 3/17 2/17 2/17
Tota l fa ce a re a (f t2 ) 17.5 17.5 25.1 31.8 23.5 x 2 25.0 x 2
Cond. fan / motor
Qty / Motor drive type 2/direct 2/direct 2/direct 2/direct 3/direct 4/direct
Motor HP / RPM 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100
Fan diameter (in) 22 22 22 22 22 22
Nominal A irflow (cfm) 6,000 6,000 6,000 6,000 9,000 12,000
Watts (total) 610 610 610 610 970 1150
* Approximate system charge with about 25 ft piping of sizes indicated with matched 524J
