APPLICATION DATA
Operating limits
Maximum outdoor temperature 125_F................
Minimum return-air temperature (524J) 55_F..........
Maximum return-air temperature (524J) 95_F..........
Range of acceptable saturation
suction temperature 20 to 50_F...................
Maximum discharge temperature 275_F..............
Minimum discharge superheat 60_F.................
NOTES:
1. Select air handler at no less than 300 cfm/ton (nomin-
al condensing unit capacity).
2. Total combined draw of the field-supplied liquid line
solenoid valve and air handler fan contactor must not
exceed 22 va. If the specified va must be exceeded,
use a remote relay to control the load.
MINIMUM OUTDOOR-AIR OPERA TING TEMPERATURE
UNIT
569J
MINIMUM OUTDOOR TEMP (_F)
Std With MotorMaster I® Control†
07A 35
–20
08A 35
12A 35
14A 35
16A 35
25A 35
12D 35
14D 35
16D 35
25D 35
† Wind baffles (field-supplied and field-installed) are re-
commended for all units with MotorMaster Ir control.
Refer to Low Ambient Temperature Control Installation
Instructions for additional information.
Refrigerant piping
IMPORTANT: Do not bury refrigerant piping
underground.
It is recommended that the refrigerant piping for all
commercial split systems include a liquid line solenoid
valve, a liquid line filter drier and a sight glass.
For refrigerant lines longer than 75 lineal ft, a liquid line
solenoid valve installed at the indoor unit and a suction
accumulator are required. Refer to the Refrigerant
Specialties Part Numbers table.
REFRIGERANT SPECIALTIES PART NUMBERS
LIQUID LINE
SIZE (in.)
LIQUID LINE
SOLENOID VALVE (LLSV)
LLSV
COIL
SIGHT
GLASS
3
/
8
EF680033 EF680037 KM680008
1
/
2
EF680035 EF680037 KM680004
5
/
8
EF680036 EF680037 KM680005
NOTE: 569J* units require TWO sets of parts.
Puron-duty Filter Drier(s)
Model-Size Qty Liquid Line OD Desiccant Volume
Part
Number Ref
569J*07 1
3
/
8
-in 8cu.in. KH43LG091
569J*08 1
1
/
2
-in 16 cu. in. KH43LG085
569J*12 1
1
/
2
-in 16 cu. in. KH43LG085
569J*14 1
5
/
8
-in 16 cu. in. KH43LG086
569J*16 1
5
/
8
-in 30 cu. in. KH43LG087
569J*25 1
5
/
8
-in 30 cu. in. KH43LG087
569J*12 2
3
/
8
-in 8cu.in. KH43LG091
569J*14 2
1
/
2
-in 16 cu. in. KH43LG085
569J*16 2
1
/
2
-in 16 cu. in. KH43LG085
569J*25 2
1
/
2
-in 16 cu. in. KH43LG085
