PERFORMANCE DATA (cont.)
569J*12A -- 524J*12 COMBINATION RATINGS
AMBIENT TEMPERATURE
85 95 105 115 125
EA (db) EA (db) EA (db) EA (db) EA (db)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
3000 Cfm
EA (wb)
58
THC 110.5 110.5 121.5 106.2 106.2 117.1 101.6 101.6 112.4 96.9 96.9 107.5 92.5 92.5 102.9
SHC 99.4 110.5 121.5 95.3 106.2 117.1 90.9 101.6 112.4 86.3 96.9 107.5 82.0 92.5 102.9
62
THC 114.0 114.0 114.0 108.8 108.8 111.4 103.3 103.3 108.7 97.6 97.6 105.6 91.2 91.2 101.6
SHC 92.3 103.2 114.0 89.9 100.6 111.4 87.3 98.0 108.7 84.5 95.1 105.6 80.8 91.2 101.6
67
THC 123.2 123.2 123.2 117.4 117.4 117.4 111.5 111.5 111.5 105.1 105.1 105.1 --- --- ---
SHC 76.4 86.8 97.2 74.1 84.4 94.7 71.7 81.9 92.1 69.1 79.3 89.4 --- --- ---
72
THC 133.0 133.0 133.0 126.8 126.8 126.8 120.4 120.4 120.4 113.5 113.5 113.5 106.0 106.0 106.0
SHC 60.2 70.1 79.9 57.9 67.7 77.5 55.6 65.3 74.9 53.2 62.7 72.3 50.5 60.0 69.4
76
THC --- 140.7 140.7 --- 134.2 134.2 --- 127.6 127.6 --- 120.2 120.2 --- 112.3 112.3
SHC --- 56.4 65.8 --- 54.1 63.4 --- 51.8 61.0 --- 49.3 58.4 --- 46.6 55.6
3500 Cfm
EA (wb)
58
THC 115.8 115.8 128.4 111.2 111.2 123.6 106.3 106.3 118.6 101.1 101.1 113.2 94.3 94.3 106.2
SHC 103.3 115.8 128.4 98.8 111.2 123.6 94.1 106.3 118.6 89.0 101.1 113.2 82.5 94.3 106.2
62
THC 117.4 117.4 124.5 112.0 112.0 121.6 106.6 106.6 118.3 101.1 101.1 113.2 93.0 93.0 104.8
SHC 99.5 112.0 124.5 96.9 109.2 121.6 93.8 106.0 118.3 89.0 101.1 113.2 81.2 93.0 104.8
67
THC 126.1 126.1 126.1 120.0 120.0 120.0 113.8 113.8 113.8 107.2 107.2 107.2 101.0 101.0 101.0
SHC 81.5 93.4 105.4 79.1 91.0 102.8 76.7 88.4 100.2 74.1 85.8 97.4 71.6 83.2 94.7
72
THC 135.6 135.6 135.6 129.2 129.2 129.2 122.6 122.6 122.6 115.5 115.5 115.5 108.0 108.0 108.0
SHC 62.8 74.1 85.4 60.5 71.7 82.9 58.2 69.3 80.4 55.7 66.7 77.7 53.2 64.0 74.9
76
THC --- 143.2 143.2 --- 136.5 136.5 --- 129.7 129.7 --- 122.1 122.1 --- --- ---
SHC --- 58.4 69.2 --- 56.1 66.8 --- 53.8 64.4 --- 51.3 61.8 --- --- ---
4000 Cfm
EA (wb)
58
THC 120.2 120.2 134.3 115.3 115.3 129.2 110.1 110.1 123.8 104.5 104.5 118.0 97.1 97.1 110.4
SHC 106.1 120.2 134.3 101.4 115.3 129.2 96.4 110.1 123.8 91.0 104.5 118.0 83.9 97.1 110.4
62
THC 120.5 120.5 133.7 115.3 115.3 129.2 110.2 110.2 123.9 104.6 104.6 118.1 97.0 97.0 110.3
SHC 105.6 119.7 133.7 101.4 115.3 129.2 96.5 110.2 123.9 91.1 104.6 118.1 83.8 97.0 110.3
67
THC 128.2 128.2 128.2 122.0 122.0 122.0 115.6 115.6 115.6 108.8 108.8 108.8 101.3 101.3 102.0
SHC 86.2 99.7 113.2 83.9 97.2 110.6 81.4 94.7 108.0 78.8 92.0 105.1 76.0 89.0 102.0
72
THC 137.6 137.6 137.6 131.0 131.0 131.0 124.2 124.2 124.2 116.9 116.9 116.9 109.3 109.3 109.3
SHC 65.2 78.0 90.7 62.9 75.6 88.2 60.6 73.1 85.7 58.1 70.6 83.0 55.6 67.8 80.1
76
THC --- 145.0 145.0 --- 138.2 138.2 --- 131.2 131.2 --- --- --- --- --- ---
SHC --- 60.3 72.5 --- 58.1 70.1 --- 55.8 67.7 --- --- --- --- --- ---
4500 Cfm
EA (wb)
58
THC 123.8 123.8 139.3 118.6 118.6 134.0 113.2 113.2 128.4 107.3 107.3 122.2 102.3 102.3 117.1
SHC 108.2 123.8 139.3 103.2 118.6 134.0 98.0 113.2 128.4 92.4 107.3 122.2 87.6 102.3 117.1
62
THC 123.9 123.9 139.4 118.7 118.7 134.1 113.3 113.3 128.4 107.4 107.4 122.3 101.8 101.8 116.5
SHC 108.3 123.9 139.4 103.3 118.7 134.1 98.1 113.3 128.4 92.5 107.4 122.3 87.1 101.8 116.5
67
THC 130.0 130.0 130.0 123.6 123.6 123.6 117.1 117.1 117.1 110.2 110.2 112.5 102.8 102.8 109.3
SHC 90.8 105.8 120.9 88.3 103.2 118.2 85.8 100.6 115.4 83.2 97.8 112.5 80.3 94.8 109.3
72
THC 139.1 139.1 139.1 132.4 132.4 132.4 125.5 125.5 125.5 118.1 118.1 118.1 110.3 110.3 110.3
SHC 67.4 81.7 95.9 65.2 79.3 93.3 62.9 76.8 90.8 60.4 74.2 88.1 57.8 71.5 85.2
76
THC --- 146.4 146.4 --- 139.6 139.6 --- --- --- --- --- --- --- --- ---
SHC --- 62.2 75.7 --- 59.9 73.3 --- --- --- --- --- --- --- --- ---
5000 Cfm
EA (wb)
58
THC 126.8 126.8 143.8 121.4 121.4 138.2 115.8 115.8 132.3 109.8 109.8 126.1 103.0 103.0 119.1
SHC 109.8 126.8 143.8 104.5 121.4 138.2 99.2 115.8 132.3 93.4 109.8 126.1 86.9 103.0 119.1
62
THC 126.9 126.9 143.9 121.4 121.4 138.2 115.9 115.9 132.4 109.8 109.8 126.2 103.1 103.1 119.2
SHC 109.8 126.9 143.9 104.6 121.4 138.2 99.3 115.9 132.4 93.5 109.8 126.2 87.0 103.1 119.2
67
THC 131.4 131.4 131.4 125.0 125.0 125.5 118.4 118.4 122.7 111.5 111.5 119.6 104.1 104.1 116.1
SHC 95.1 111.7 128.2 92.6 109.1 125.5 90.1 106.4 122.7 87.3 103.4 119.6 84.2 100.1 116.1
72
THC 140.3 140.3 140.3 133.5 133.5 133.5 126.6 126.6 126.6 119.0 119.0 119.0 111.1 111.1 111.1
SHC 69.6 85.3 100.9 67.4 82.9 98.4 65.1 80.5 95.9 62.6 77.9 93.2 60.0 75.1 90.3
76
THC --- 147.6 147.6 --- --- --- --- --- --- --- --- --- --- --- ---
SHC --- 64.0 78.8 --- --- --- --- --- --- --- --- --- --- --- ---
--- Not operational
THC --- Total Cooling Capacity, Gross (1,000 Btuh)
SHC --- Sensible Cooling Capacity, Gross (1,000 Btuh)
