Bryant Legacy Line Series User Manual

11
NOTES:
1. Included with economizer.
2. Sensors used to optimize economizer performance.
3. See application data for assistance.
4. Available on units with MOCPs of 80 amps or less.
5. Not available as factory-installed option on single phase (208-230/1/60) models. Use field-installed accessory where available.
6. FDD (Fault Detection and Diagnostic) capability per California Title 24 section 120.2.
7. Models with RTU Open DDC controls comply with California Title 24 Fault Detection and Diagnostic (FDD).
CATEGORY ITEM
FACTORY-
INSTALLED OPTION
FIELD-INSTALLED
ACCESSORY
CABINET
Thru-the-base electrical or gas-line connections X X
Hinged Access Panels X
COIL OPTIONS
Cu/Cu indoor and/or outdoor coils
5
X
Pre-coated outdoor coils
5
X
Premium, E-coated outdoor coils
5
X
HUMIDITY CONTROL Perfect Humidity™ Dehumidification System
5
X
CONDENSER
PROTECTION
Condenser coil hail guard (louvered design)
5
XX
CONTROLS
Thermostats, temperature sensors, and subbases X
RTU Open multi-protocol controller X
Smoke detector (supply and/or return air) X
Time Guard II compressor delay control circuit X
Phase Monitor X
ECONOMIZERS AND
OUTDOOR AIR DAMPERS
EconoMi$er IV for electro-mechnical controls - Non FDD (Standard
air leak damper models)
5, 6
XX
EconoMi$er2 for DDC controls, complies with FDD (Standard and
Ultra Low Leak air damper models)
5, 7
XX
Motorized 2-position outdoor air damper
5
XX
Manual outdoor air damper (25% and 50%) X
Barometric relief
1
XX
Power exhaust X
EconoMi$er X for electro-mechanical controls, complies with FDD.
(Standard and Ultra Low Leak air damper models)
5, 6
XX
ECONOMIZER SENSORS
AND IAQ DEVICES
Single dry bulb temperature sensors
2
XX
Differential dry bulb temperature sensors
2
X
Single enthalpy sensors
2
XX
Differential enthalpy sensors
2
X
Wall-mounted or duct-mounted CO
2
sensor
2
X
Unit-mounted CO
2
sensor
2
X
GAS HEAT
Propane conversion kit X
Stainless steel heat exchanger X
High altitude conversion kit X
Flue Shield X
Flue Discharge Deflector X
INDOOR MOTOR AND
DRIVE
Multiple motor and drive packages X
LOW AMBIENT CONTROL
Winter start kit
3
X
Motormaster
®
head pressure controller
3
X
POWER OPTIONS
Convenience outlet (powered)
5
X
Convenience outlet (non-powered) X
Non-fused disconnect
4
X
ROOF CURBS
Roof curb 14-in. (356mm) X
Roof curb 24-in. (610mm) X
OPTIONS AND ACCESSORIES
