LEGEND NOTES:
1. Rated in accordance with AHRI Standard 210/240.
2. Ratings are based on:
Cooling Standard: 80°F (27°C) db, 67°F (19°C) wb indoor air tempera-
ture and 95°F (35°C) db outdoor air temperature.
3. All 582J units comply with ASHRAE 90.1 and Department of Energy
(DOE) Energy Standard for minimum SEER and EER requirements.
4. All 582J units comply with US Energy Policy Act (2005). To evaluate
code compliance requirements, refer to state and local codes.
NOTES:
1. Heat ratings are for natural gas heat exchangers operated at or below
2000 ft (610 m). For information on propane or altitudes above 2000 ft
(610 m), see the Application Data section of this book. Accessory Pro-
pane/High Altitude kits are also available.
2. In the USA, the input rating for altitudes above 2000 ft (610 m) must be
de-rated by 4% for each 1000 ft (305 m) above sea level. In Canada, the
input rating must be de-rated by 10% for altitudes of 2000 ft (610) to
4500 ft (1372 m) above sea level.
AHRI COOLING RATING TABLE
UNIT COOLING STAGES
NOM. CAPACITY
(TONS)
NET COOLING
CAPACITY (MHBH)
TOTAL POWER
(kW)
SEER EER
582J*04 1 3 35.4 3.0 14.0 12.00
582J*05 1 4 47.5 4.0 14.0 12.00
582J*06 1 5 58.5 4.9 14.1 12.00
AHRI — Air-Conditioning, Heating, and Refrigeration Institute Test
Standard
ASHRAE — American Society of Heating, Refrigerating, and Air-Condition-
ing Engineers
EER — Energy Efficiency Ratio
SEER — Seasonal Energy Efficiency Ratio
HEATING RATING TABLE - NATURAL GAS AND PROPANE
582J UNITS GAS HEAT
AL/SS HEAT EXCHANGER
TEMP RISE
(DEG F)
THERMAL EFFICIENCY (%) AFUE (%)
INPUT/OUTPUT
STAGE 1 (MBH)
INPUT/OUTPUT
STAGE 2 (MBH)
SINGLE
PHASE
04
LOW – 65/53 25-55 82.0% 81.0%
MED – 90/73.5 45-85 82.0% 81.2%
HIGH – – – – –
05
LOW – 65/53 20-55 82.0% 81.0%
MED – 90/73.5 30-65 82.0% 81.2%
HIGH – 130/106 45-80 82.0% 81.0%
06
LOW – 65/53 15-55 82.0% 81.0%
MED – 90/73.5 25-65 82.0% 81.2%
HIGH – 130/106 35-80 82.0% 81.0%
THREE
PHASE
04
LOW – 72/59 25-55 82.0% N/A
MED 82/66 115/93 55-85 81.0% N/A
HIGH – – – – –
05
LOW – 72/59 25-55 82.0% N/A
MED – 115/93 35-65 81.0% N/A
HIGH 120/96 150/120 50-80 80.0% N/A
06
LOW – 72/59 20-55 82.0% N/A
MED – 115/93 30-65 81.0% N/A
HIGH 120/96 150/120 40-80 80.0% N/A
AHRI CAPACITY RATINGS
