Bryant Legacy Line Series - Electrical Data

41
582J*04 SINGLE STAGE COOLING WITH SINGLE SPEED INDOOR FAN MOTOR (3 TONS)
V-PH-HZ
UNIT VOLTAGE COMP 1 OFM (ea) IFM
RANGE
RLA LRA WATTS FLA TYPE
EFF at Full
Load
FLA
MIN MAX
208-1-60 187 253 16.6 79
190 1.0 DD-STD 78% 7.4
190 1.0 MED 67% 4.9
190 1.0 HIGH 76% 7.0
230-1-60 187 253 16.6 79
190 1.0 DD-STD 78% 7.4
190 1.0 MED 67% 4.9
190 1.0 HIGH 76% 7.0
208-3-60 187 253 10.4 73
190 1.0 DD-STD 78% 7.4
190 1.0 MED 87% 5.2
190 1.0 HIGH 89% 8.4
230-3-60 187 253 10.4 73
190 1.0 DD-STD 78% 7.4
190 1.0 MED 87% 4.9
190 1.0 HIGH 89% 8.3
460-3-60 414 506 5.8 38
190 0.5 DD-STD 78% 4.0
190 0.5 MED 87% 2.5
190 0.5 HIGH 89% 4.2
575-3-60 518 633 3.8 37
190 0.5 DD-STD 78% 4.0
190 0.5 MED 72% 1.6
190 0.5 HIGH 77% 2.8
582J*05 SINGLE STAGE COOLING WITH SINGLE SPEED INDOOR FAN MOTOR (4 TONS)
V-PH-HZ
UNIT VOLTAGE COMP 1 OFM (ea) IFM
RANGE
RLA LRA WATTS FLA TYPE
EFF at Full
Load
FLA
MIN MAX
208-1-60 187 253 21.8 117
325 1.5 DD-STD 78% 7.4
325 1.5 MED 67% 4.9
325 1.5 HIGH 76% 7.0
230-1-60 187 253 21.8 117
325 1.5 DD-STD 78% 7.4
325 1.5 MED 67% 4.9
325 1.5 HIGH 76% 7.0
208-3-60 187 253 13.7 83
325 1.5 DD-STD 78% 7.4
325 1.5 MED 87% 5.2
325 1.5 HIGH 89% 8.4
230-3-60 187 253 13.7 83
325 1.5 DD-STD 78% 7.4
325 1.5 MED 87% 4.9
325 1.5 HIGH 89% 8.3
460-3-60 414 506 6.2 41
325 0.8 DD-STD 78% 4.0
325 0.8 MED 87% 2.5
325 0.8 HIGH 89% 4.2
575-3-60 518 633 4.8 33
325 0.6 DD-STD 78% 4.0
325 0.6 MED 72% 1.6
325 0.6 HIGH 77% 2.8
ELECTRICAL DATA
