TABLE OF CONTENTS
PAGE
FEATURES/BENEFITS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
MODEL NUMBER NOMENCLATURE . . . . . . . . . . . . . . . 4
AHRI CAPACITY RATINGS . . . . . . . . . . . . . . . . . . . . . . . . 5
PHYSICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
OPTIONS AND ACCESSORIES . . . . . . . . . . . . . . . . . . . . 11
BASE UNIT DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . 15
PAGE
APPLICATION DATA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
PERFORMANCE DATA. . . . . . . . . . . . . . . . . . . . . . . . . . . .21
ELECTRICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
SEQUENCE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . .44
GUIDE SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . .47
The Bryant rooftop unit (RTU) was designed by customers for customers. With “no-strip screw” collars, handled access panels, and
more, we’ve made your unit easy to install, easy to maintain and easy to use.
Easy to install:
All Legacy Line™ units are field-convertible to horizontal air flow, which makes it easy to adjust to unexpected job site complica-
tions. Lighter units make easy replacement. Bryant 582J rooftops fit on existing Bryant curbs dating back to 1989. Also, our large
control box gives you room to work and room to mount Bryant accessory controls.
Easy to maintain:
Easy access handles by Bryant provide quick and easy access to all normally serviced components. Our “no-strip” screw system has
superior holding power and guides screws into position while preventing the screw from stripping the unit’s metal. Take accurate
pressure readings by reading condenser pressure with panels on. Simply remove the black, composite plug, route your gage line(s)
through the hole, and connect them to the refrigeration service valve(s).
Easy to use:
The newly designed central terminal board by Bryant puts all your connections and troubleshooting points in one convenient place,
standard. Most low voltage connections are made to the same board, which makes it easy to find what you’re looking for and easy
to access it. Bryant rooftops have high and low pressure switches, a filter drier, and 2-in. (51mm) filters standard.
