PHYSICAL DATA (COOLING) 3-5 TONS
582J*04A/B 582J*05A/B 582J*06A/B
REFERIGERATION SYSTEM
# Circuits / # Comp. / Type 1 / 1 / Scroll 1 / 1 / Scroll 1 / 1 / Scroll
Puron
®
refrig. (R-410A) A 1 phase (lbs-oz) 7-2 10-8 16-0
Puron
®
refrig. (R-410A) A 3 phase (lbs-oz) 7-2 10-8 14-8
Perfect Humidity™ Puron
®
refrig. (R-410A) charge A (lbs-oz) 10-6 15-5 26-0
oil A/B (oz) 25 42 42
Metering Device Acutrol Acutrol Acutrol
Perfect Humidity Metering Device Acutrol + TXV Acutrol + TXV Acutrol + TXV
High-press. Trip / Reset (psig) 630/505 630/505 630/505
Low-press. Trip / Reset (psig) 54/117 54/117 54/117
Loss of charge Trip/Reset (psig) N/A N/A N/A
EVAPORATION COIL
Material (Tube/Fin) Cu/Al Cu/Al Cu/Al
Coil Type
3
/
8
-in. RTPF
3
/
8
-in. RTPF
3
/
8
-in. RTPF
Rows / FPI 3 / 15 3 / 15 4 / 15
Total Face Area (ft
2
) 5.5 5.5 7.3
Condensate Drain Conn. Size
3
/
4
-in.
3
/
4
-in.
3
/
4
-in.
PERFECT HUMIDITY COIL
Material (Tube/Fin) Cu/Al Cu/Al Cu/Al
Coil Type
3
/
8
-in. RTPF
3
/
8
-in. RTPF
3
/
8
-in. RTPF
Rows / FPI 1 / 17 2 / 17 2 / 17
Total Face Area (ft
2
) 3.9 3.9 5.2
EVAP. FAN AND MOTOR
STANDARD STATIC
1 PHASE
Motor Qty / Drive Type 1 / Direct 1 / Direct 1 / Direct
Max BHP111
RPM Range 600-1200 600-1200 600-1200
Motor Frame Size 48 48 48
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
MEDIUM STATIC
1 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt 1 / Belt
Max BHP 1.2 1.2 1.5
RPM Range 770-1175 770-1175 1035-1466
Motor Frame Size 48 48 56
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
HIGH STATIC
1 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt N/A
Max BHP 1.5 1.5 N/A
RPM Range 1035-1466 1035-1466 N/A
Motor Frame Size 56 56 N/A
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal N/A
Fan Diameter (in.) 10 x 10 10 x 10 N/A
STANDARD STATIC
3 PHASE
Motor Qty / Drive Type 1 / Direct 1 / Direct 1 / Direct
Max BHP111
RPM Range 600-1200 600-1200 600-1200
Motor Frame Size 48 48 48
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 11 x 10
MEDIUM STATIC
3 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt 1 / Belt
Max BHP 1.7 1.7 2.9
RPM Range 770-1175 920-1303 1035-1466
Motor Frame Size 48 56 56
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
HIGH STATIC
3 PHASE
Motor Qty / Drive Type 1 / Belt 1 / Belt 1 / Belt
Max BHP 2.9 2.9 2.9
RPM Range 1035-1466 1208-1550 1303-1550
Motor Frame Size 56 56 56
Fan Qty / Type 1 / Centrifugal 1 / Centrifugal 1 / Centrifugal
Fan Diameter (in.) 10 x 10 10 x 10 10 x 10
PHYSICAL DATA
