Bryant Legacy Line Series - Condenser Coil and Fan;Motor Data; Filter Specifications

8
N/A – Not applicable
COND. COIL
1 phase Material (Tube/Fin) Cu/Al Cu/Al Cu/Al
Coil Type
3
/
8
-in. RTPF
3
/
8
-in. RTPF
3
/
8
-in. RTPF
Rows / FPI 1 / 17 2 / 17 2 / 17
Total Face Area (ft
2
) 16.5 16.5 21.3
3 phase Material (Tube/Fin)
Coil Type
3
/
8
-in. RTPF
3
/
8
-in. RTPF
3
/
8
-in. RTPF
Rows / FPI 1/17 2/17 2/17
Total Face Area (ft
2
) 16.5 14.6 18.8
COND. FAN / MOTOR
Qty / Motor Drive Type 1 / Direct 1 / Direct 1 / Direct
Motor HP / RPM 1 / 8 / 825 1 / 4 / 1100 1 / 4 / 1100
Fan diameter (in.) 22 22 22
FILTERS
RA Filter # / Size (in.) 2 / 16 x 25 x 2 2 / 16 x 25 x 2 4 / 16 x 16 x 2
OA inlet screen # / Size (in.) 1 / 20 x 24 x 1 1 / 20 x 24 x 1 1 / 20 x 24 x 1
PHYSICAL DATA (COOLING) 3-5 TONS (cont)
582J*04A/B 582J*05A/B 582J*06A/B
PHYSICAL DATA (CONT)
