32
582J*05 VERTICAL UNIT - DIRECT DRIVE
SPEED
(TORQUE) TAP
CFM ESP BHP
1
1200 0.35 0.36
1300 0.17 0.34
1400 0.01 0.32
1500 — —
1600 — —
1700 — —
1800 — —
1900 — —
2000 — —
2
1200 0.47 0.42
1300 0.28 0.39
1400 0.10 0.36
1500 — —
1600 — —
1700 — —
1800 — —
1900 — —
2000 — —
3
1200 0.77 0.55
1300 0.66 0.58
1400 0.54 0.60
1500 0.40 0.61
1600 0.25 0.60
1700 0.07 0.60
1800 — —
1900 — —
2000 — —
4
1200 0.78 0.55
1300 0.68 0.58
1400 0.58 0.61
1500 0.46 0.64
1600 0.35 0.66
1700 0.22 0.68
1800 0.09 0.70
1900 — —
2000 — —
5
1200 0.81 0.56
1300 0.72 0.59
1400 0.66 0.62
1500 0.55 0.66
1600 0.41 0.69
1700 0.29 0.73
1800 0.17 0.76
1900 0.05 0.80
2000 -0.06 0.83
582J*05 HORIZONTAL UNIT - DIRECT DRIVE
SPEED
(TORQUE) TAP
CFM ESP BHP
1
1200 0.57 0.41
1300 0.40 0.39
1400 0.24 0.37
1500 0.08 0.35
1600 — —
1700 — —
1800 — —
1900 — —
2000 — —
2
1200 0.69 0.46
1300 0.52 0.45
1400 0.36 0.43
1500 0.18 0.40
1600 0.00 0.39
1700 — —
1800 — —
1900 — —
2000 — —
3
1200 0.91 0.56
1300 0.83 0.59
1400 0.74 0.62
1500 0.64 0.64
1600 0.52 0.66
1700 0.39 0.66
1800 0.22 0.63
1900 0.03 0.62
2000 — —
4
1200 0.92 0.56
1300 0.83 0.60
1400 0.75 0.63
1500 0.67 0.66
1600 0.58 0.69
1700 0.49 0.72
1800 0.39 0.74
1900 0.26 0.76
2000 0.12 0.76
5
1200 0.95 0.57
1300 0.88 0.61
1400 0.80 0.64
1500 0.72 0.68
1600 0.64 0.71
1700 0.55 0.75
1800 0.46 0.79
1900 0.37 0.83
2000 0.27 0.87
PERFORMANCE DATA (CONT)
