Bryant PREFERRED 581J - Page 27

27
TABLE 13 – COOLING CAPACITIES 1--STAGE COOLING 4 TONS
581J*05A
AMBIENT TEMPERATU RE
85 95 105 115 125
EA (dB) EA (dB) EA (dB) EA (dB) EA (dB)
75 80 85 75 80 85 75 80 85 75 80 85 75 80 85
1200
Cfm
EA
(wb)
58
TC 43.2 43.2 49.1 41.5 41.5 47.2 39.7 39.7 45.1 37.7 37.7 42.9 35.6 35.6 40.4
SHC 37.3 43.2 49.1 35.9 41.5 47.2 34.3 39.7 45.1 32.6 37.7 42.9 30.7 35.6 40.4
62
TC 45.9 45.9 46.0 43.7 43.7 45.0 41.3 41.3 43.8 38.8 38.8 42.6 36.0 36.0 41.2
SHC 33.5 39.8 46.0 32.5 38.7 45.0 31.3 37.6 43.8 30.1 36.3 42.6 28.8 35.0 41.2
67
TC 50.5 50.5 50.5 48.0 48.0 48.0 45.4 45.4 45.4 42.6 42.6 42.6 39.6 39.6 39.6
SHC 27.9 34.1 40.4 26.8 33.1 39.4 25.7 32.0 38.2 24.5 30.8 37.1 23.2 29.5 35.8
72
TC 55.4 55.4 55.4 52.7 52.7 52.7 49.9 49.9 49.9 46.8 46.8 46.8 43.5 43.5 43.5
SHC 22.0 28.4 34.7 21.0 27.3 33.7 19.9 26.2 32.5 18.7 25.0 31.3 17.4 23.8 30.1
78
TC --- 59.7 59.7 --- 56.8 56.8 --- 53.7 53.7 --- 50.4 50.4 --- 46.8 46.8
SHC --- 23.6 30.2 --- 22.6 29.2 --- 21.5 28.1 --- 20.3 26.8 --- 19.1 25.5
1400
Cfm
EA
(wb)
58
TC 45.6 45.6 51.9 43.8 43.8 49.8 41.9 41.9 47.6 39.7 39.7 45.1 37.3 37.3 42.4
SHC 39.4 45.6 51.9 37.9 43.8 49.8 36.2 41.9 47.6 34.3 39.7 45.1 32.3 37.3 42.4
62
TC 47.4 47.4 50.5 45.1 45.1 49.3 42.6 42.6 48.0 40.0 40.0 46.5 37.4 37.4 44.2
SHC 36.0 43.2 50.5 34.9 42.1 49.3 33.7 40.9 48.0 32.4 39.5 46.5 30.6 37.4 44.2
67
TC 52.1 52.1 52.1 49.5 49.5 49.5 46.7 46.7 46.7 43.7 43.7 43.7 40.5 40.5 40.5
SHC 29.5 36.8 44.0 28.4 35.7 42.9 27.3 34.5 41.8 26.0 33.3 40.5 24.7 32.0 39.2
72
TC 57.1 57.1 57.1 54.3 54.3 54.3 51.2 51.2 51.2 48.0 48.0 48.0 44.5 44.5 44.5
SHC 22.8 30.1 37.4 21.7 29.0 36.3 20.5 27.8 35.1 19.3 26.6 33.9 18.0 25.3 32.6
78
TC --- 61.4 61.4 --- 58.3 58.3 --- 55.1 55.1 --- 51.6 51.6 --- 47.8 47.8
SHC --- 24.6 32.2 --- 23.5 31.1 --- 22.4 29.9 --- 21.2 28.7 --- 19.9 27.4
1600
Cfm
EA
(wb)
58
TC 47.7 47.7 54.2 45.8 45.8 52.0 43.7 43.7 49.6 41.3 41.3 47.0 38.8 38.8 44.1
SHC 41.2 47.7 54.2 39.5 45.8 52.0 37.7 43.7 49.6 35.7 41.3 47.0 33.5 38.8 44.1
62
TC 48.7 48.7 54.5 46.3 46.3 53.2 43.7 43.7 51.7 41.4 41.4 48.9 38.8 38.8 45.9
SHC 38.3 46.4 54.5 37.1 45.2 53.2 35.8 43.7 51.7 33.9 41.4 48.9 31.8 38.8 45.9
67
TC 53.3 53.3 53.3 50.6 50.6 50.6 47.7 47.7 47.7 44.6 44.6 44.6 41.2 41.2 42.6
SHC 31.0 39.2 47.5 29.9 38.1 46.3 28.7 37.0 45.2 27.5 35.7 43.9 26.2 34.4 42.6
72
TC 58.4 58.4 58.4 55.4 55.4 55.4 52.3 52.3 52.3 48.9 48.9 48.9 45.2 45.2 45.2
SHC 23.4 31.7 39.9 22.3 30.6 38.8 21.1 29.4 37.6 19.9 28.2 36.4 18.6 26.8 35.1
78
TC --- 62.7 62.7 --- 59.5 59.5 --- 56.1 56.1 --- 52.5 52.5 --- 48.6 48.6
SHC --- 25.5 34.0 --- 24.4 32.9 --- 23.2 31.7 --- 22.0 30.4 --- 20.7 29.1
1800
Cfm
EA
(wb)
58
TC 49.5 49.5 56.2 47.4 47.4 53.9 45.2 45.2 51.3 42.7 42.7 48.5 40.1 40.1 45.5
SHC 42.8 49.5 56.2 41.0 47.4 53.9 39.0 45.2 51.3 36.9 42.7 48.5 34.6 40.1 45.5
62
TC 49.8 49.8 58.1 47.5 47.5 56.1 45.2 45.2 53.4 42.8 42.8 50.5 40.1 40.1 47.4
SHC 40.4 49.2 58.1 38.8 47.5 56.1 37.0 45.2 53.4 35.0 42.8 50.5 32.8 40.1 47.4
67
TC 54.3 54.3 54.3 51.5 51.5 51.5 48.5 48.5 48.5 45.3 45.3 47.1 41.8 41.8 45.7
SHC 32.5 41.7 50.8 31.4 40.5 49.7 30.2 39.3 48.5 28.9 38.0 47.1 27.5 36.6 45.7
72
TC 59.4 59.4 59.4 56.3 56.3 56.3 53.1 53.1 53.1 49.6 49.6 49.6 45.8 45.8 45.8
SHC 24.0 33.2 42.4 22.9 32.1 41.3 21.7 30.9 40.1 20.4 29.6 38.8 19.1 28.3 37.5
78
TC --- 63.8 63.8 --- 60.5 60.5 --- 57.0 57.0 --- 53.2 53.2 --- 49.2 49.2
SHC --- 26.3 35.8 --- 25.2 34.6 --- 24.0 33.4 --- 22.8 32.1 --- 21.5 30.8
2000
Cfm
EA
(wb)
58
TC 51.0 51.0 58.0 48.8 48.8 55.5 46.5 46.5 52.8 43.9 43.9 49.9 41.1 41.1 46.7
SHC 44.1 51.0 58.0 42.2 48.8 55.5 40.2 46.5 52.8 37.9 43.9 49.9 35.5 41.1 46.7
62
TC 51.1 51.1 60.4 48.9 48.9 57.8 46.5 46.5 55.0 44.0 44.0 51.9 41.1 41.1 48.6
SHC 41.8 51.1 60.4 40.0 48.9 57.8 38.1 46.5 55.0 36.0 44.0 51.9 33.7 41.1 48.6
67
TC 55.1 55.1 55.1 52.1 52.1 52.9 49.1 49.1 51.6 45.8 45.8 50.2 42.3 42.3 48.7
SHC 33.9 44.0 54.1 32.7 42.8 52.9 31.5 41.5 51.6 30.2 40.2 50.2 28.8 38.8 48.7
72
TC 60.3 60.3 60.3 57.1 57.1 57.1 53.7 53.7 53.7 50.1 50.1 50.1 46.3 46.3 46.3
SHC 24.5 34.7 44.8 23.4 33.5 43.6 22.2 32.3 42.4 21.0 31.1 41.2 19.6 29.7 39.8
78
TC --- 64.6 64.6 --- 61.2 61.2 --- 57.6 57.6 --- 53.8 53.8 --- 49.7 49.7
SHC --- 27.1 37.5 --- 26.0 36.3 --- 24.8 35.1 --- 23.5 33.8 --- 22.2 32.4
LEGEND:
--- --- D o n o t o p e r a t e
Cfm --- Cubic feet per minute (supply air)
EAT(db) --- Entering air temperature (dry bulb)
EAT(wb) --- Entering air temperature (wet bulb)
SHC --- Sensible heat capacity
TC --- Total capacity
581J
