ELECTRICAL INFORMATION (CON’T)
TABLE 42 – 581J*08D----2--STAGE COOLING----7.5 TONS
V --- P h --- H z
VOLTAGE COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RANGE
RLA LRA RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full
Load
FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 13.6 83 13.6 83 325 1.5
STD 1448 5.5 80% 5.2
MED 2278 7.9 81% 7.5
HIGH 4400 15.0 81% 15.0
2 3 0 --- 3 --- 6 0 187 253 13.6 83 13.6 83 325 1.5
STD 1448 5.5 80% 5.2
MED 2278 7.9 81% 7.5
HIGH 4400 15.0 81% 15.0
4 6 0 --- 3 --- 6 0 414 506 6.1 41 6.1 41 325 0.8
STD 1448 2.7 80% 2.6
MED 2278 3.6 81% 3.4
HIGH 4400 7.4 81% 7.4
5 7 5 --- 3 --- 6 0 518 633 4.2 33 4.2 33 325 0.6
STD 1379 2.5 80% 2.4
MED 3775 2.9 81% 2.8
HIGH 4400 5.9 81% 5.6
TABLE 43 – 581J*09D----2--STAGE COOLING----8.5 TONS
V --- P h --- H z
VOLTAGE COMP (Cir 1) COMP (Cir 2) OFM (ea) IFM
RANGE
RLA LRA RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full
Load
FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 13.7 83 13.7 83 325 1.5
STD 1448 5.46 80% 5.2
MED 2120 5.46 80% 5.2
HIGH 2694 10.5 80% 10.0
2 3 0 --- 3 --- 6 0 187 253 13.7 83 13.7 83 325 1.5
STD 1448 5.46 80% 5.2
MED 2120 5.46 80% 5.2
HIGH 2694 10.5 80% 10.0
4 6 0 --- 3 --- 6 0 414 506 6.2 41 6.2 41 325 0.8
STD 1448 2.73 80% 2.6
MED 2120 2.73 80% 2.6
HIGH 2694 4.62 80% 4.4
5 7 5 --- 3 --- 6 0 518 633 4.8 37 4.8 37 325 0.6
STD 1379 2.52 80% 2.4
MED 1390 2.1 80% 2.0
HIGH 3775 2.94 81% 2.8
