ELECTRICAL INFORMATION (CON’T)
TABLE 40 – 581J*06A----1--STAGE COOLING----5 TONS
V --- P h --- H z
VOLTAGE COMP (ea) OFM (ea) IFM
RANGE
RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full Load FLA
MIN MAX
2 0 8 --- 1 --- 6 0 187 253 25.0 134 325 1.4 D D --- S T D 980 7.8 84% 7.4 2 3 0 --- 1 --- 6 0 187 253 25.0 134 325 1.4 D D --- S T D 980 7.8 84% 7.4 2 0 8 --- 3 --- 6 0 187 253 15.9 110 325 1.4
D D --- S T D 980 7.8 84% 7.4
MED 2120 5.5 80% 5.2
HIGH 2615 7.9 81% 7.5
2 3 0 --- 3 --- 6 0 187 253 15.9 110 325 1.4
D D --- S T D 980 7.8 84% 7.4
MED 2120 5.5 80% 5.2
HIGH 2615 7.9 81% 7.5
4 6 0 --- 3 --- 6 0 414 506 7.0 52 325 0.9
D D --- S T D 980 4.2 84% 4.0
MED 2120 2.7 80% 2.6
HIGH 2615 3.6 81% 3.4
5 7 5 --- 3 --- 6 0 518 633 5.1 40 325 0.9
D D --- S T D 980 4.2 84% 4.0
MED 1390 2.1 81% 2.0
HIGH 3775 2.9 81% 2.8
TABLE 41 – 581J*07A----1--STAGE COOLING----6 TONS
V --- P h --- H z
VOLTAGE COMP (ea) OFM (ea) IFM
RANGE
RLA LRA WATTS FLA TYPE
Max
WATTS
Max
AMP Draw
EFF at Full Load FLA
MIN MAX
2 0 8 --- 3 --- 6 0 187 253 19.0 123 325 1.5
STD 2120 5.5 80% 5.2
MED 2615 7.9 81% 7.5
HIGH 2615 15.8 81% 15.0
2 3 0 --- 3 --- 6 0 187 253 19.0 123 325 1.5
STD 2120 5.5 80% 5.2
MED 2615 7.9 81% 7.5
HIGH 2615 15.8 81% 15.0
4 6 0 --- 3 --- 6 0 414 506 9.7 62 325 0.8
STD 2120 2.7 80% 2.6
MED 2615 3.6 81% 3.4
HIGH 3775 7.8 81% 7.4
5 7 5 --- 3 --- 6 0 518 633 7.4 50 325 0.6
STD 2120 2.5 80% 2.4
MED 3775 2.9 81% 2.8
HIGH 3775 5.9 81% 5.6
