Bryant PREFERRED 581J - Page 40

40
TABLE 33 – 581J*05A Horizontal Unit--Direct Drive
Speed
(Torque)
tap
CFM ESP BHP
1
1200 0.49 0.35
1300 0.34 0.33
1400 0.20 0.31
1500 0.06 0.29
1600 --- ---
1700 --- ---
1800 --- ---
1900 --- ---
2000 --- ---
2
1200 0.60 0.40
1300 0.45 0.38
1400 0.30 0.36
1500 0.16 0.34
1600 0.01 0.32
1700 --- ---
1800 --- ---
1900 --- ---
2000 --- ---
3
1200 0.94 0.59
1300 0.83 0.61
1400 0.71 0.63
1500 0.59 0.61
1600 0.46 0.59
1700 0.33 0.56
1800 0.19 0.53
1900 0.07 0.49
2000 --- ---
4
1200 0.98 0.59
1300 0.89 0.62
1400 0.81 0.65
1500 0.72 0.66
1600 0.62 0.67
1700 0.52 0.68
1800 0.40 0.68
1900 0.27 0.66
2000 0.12 0.61
5
1200 1.02 0.60
1300 0.95 0.63
1400 0.81 0.67
1500 0.72 0.70
1600 0.74 0.74
1700 0.67 0.78
1800 0.59 0.82
1900 0.51 0.86
2000 0.42 0.89
TABLE 34 – 581J*05A Vertical Unit--Direct Drive
Speed
(Torque)
tap
CFM ESP BHP
1
1200 0.38 0.30
1300 0.24 0.28
1400 0.12 0.27
1500 0.01 0.26
1600 --- ---
1700 --- ---
1800 --- ---
1900 --- ---
2000 --- ---
2
1200 0.49 0.34
1300 0.34 0.32
1400 0.20 0.31
1500 0.05 0.29
1600 --- ---
1700 --- ---
1800 --- ---
1900 --- ---
2000 --- ---
3
1200 0.87 0.56
1300 0.74 0.57
1400 0.60 0.59
1500 0.44 0.56
1600 0.29 0.50
1700 0.14 0.47
1800 0.02 0.46
1900 --- ---
2000 --- ---
4
1200 0.93 0.57
1300 0.83 0.60
1400 0.72 0.63
1500 0.60 0.63
1600 0.48 0.62
1700 0.35 0.62
1800 0.21 0.61
1900 0.06 0.58
2000 --- ---
5
1200 0.97 0.58
1300 0.89 0.61
1400 0.72 0.65
1500 0.60 0.68
1600 0.64 0.72
1700 0.55 0.75
1800 0.46 0.79
1900 0.35 0.82
2000 0.25 0.86
581J
