Bryston 7B SST - System Block Diagrams

7B SST Series Amplifier
8
SOFT
START
AND
LOGIC
CONTROL
AC INPUT
REMOTE
TRIGGER
ON
MODULE 2
MODULE MUTE
MODULE MUTE
MODULE 1
TEMPERATURE
MONITOR
INPUT
SELECT
SWITCH
REGULATED
LOW
VOLTAGE
SUPPLY
POWER
AMPLIFIER
CLIPING
AND
CURCUIT
MONITOR
INPUT
BUFFER
AND GAIN
STAGE
SENSITIVTY
AND GAIN
SWITCH
+/-30Vdc
+/-30Vdc
XLR OR
PHONE
INPUT
SINGLE ENDED
INPUT
DEDICATED HIGH
CURRENT POWER
SUPPLY
+/-65Vdc
OUTPUT
LED
TEMPERATURE
MONITOR
REGULATED
LOW
VOLTAGE
SUPPLY
POWER
AMPLIFIER
CLIPING
AND
CURCUIT
MONITOR
INVERTER
+/-30Vdc
+/-30Vdc
DEDICATED HIGH
CURRENT POWER
SUPPLY
+/-65Vdc
OUTPUT
BLUE BINDING POST
RED BINDING POST
(INVERTED)
(NON INVERTED)
