Bticino Legrand MyHome User Manual

1918
Thermostat with display
Installer manual
5 Functions and operating modes
(*) Connection and configuration detail F430R8
OUT 1 = minimum fan speed
OUT 2 = medium fan speed
OUT 3 = maximum fan speed
OUT 4 = heating solenoid valve
OUT 5 = cooling solenoid valve
F430R8
M
OUT 3
OUT 2
OUT 1
N
L1 L2
F430R8
OUT 5
OUT 4
OUT 3
OUT 2
OUT 1
OUT 5
OUT 4
L
N
230 Vac
BEDROOM 1 ACTUATOR
[ZA] [ZB] [N] [TYPE]
0 1 1
BEDROOM 3 ACTUATOR
[ZA] [ZB] [N] [TYPE]
0 3 1
BEDROOM 2 ACTUATOR
[ZA] [ZB] [N] [TYPE]
0 2 1
BEDROOM 4 ACTUATOR
[ZA] [ZB] [N] [TYPE]
0 4 1
