Bticino Legrand MyHome User Manual

1716
Thermostat with display
Installer manual
5.3 Example of installation diagram
4 zone system with 4 tube fan-coil for heating and cooling systems.
Chiller
Boiler
E49
H/LN4691
F430R8
BEDROOM 4
(**)
(*)
PRI
PRI: 220 – 240 V~
185 – 175 mA
47/63 Hz
SCS: 27 Vdc
600 mA
SCS
E49
MH201
MH201
E49
H/LN4691
F430R8
BEDROOM 1
(**)
(*)
PRI
PRI: 220 – 240 V~
185 – 175 mA
47/63 Hz
SCS: 27 Vdc
600 mA
SCS
E49
MH201
MH201
E49
H/LN4691
F430R8
BEDROOM 2
(**)
(*)
PRI
PRI: 220 – 240 V~
185 – 175 mA
47/63 Hz
SCS: 27 Vdc
600 mA
SCS
E49
MH201
MH201
E49
H/LN4691
F430R8
BEDROOM 3
(**)
(*)
PRI
PRI: 220 – 240 V~
185 – 175 mA
47/63 Hz
SCS: 27 Vdc
600 mA
SCS
E49
MH201
MH201
2 3
4
5 6
1
DC - In
HUB SWITCH 10/100
LAN network
Computer with supervision software
LAN network
