2928
Thermostat with display
Installer manual
7 Appendix
7.1 Installation height
The thermostat must be installed on a wall at an average height of 150 cm from the floor, unless
otherwise required by current laws.
MODE
+
–
FAN
150 cm
7.2 Technical data
Power supply from BUS 18 – 27 Vdc
AAbsorption
30 mA (maximum backlighting while the keys are
being pressed)
16 mA (backlighting during stand-by)
13 mA (backlighting off)
Unit of measure °C or °F
Operating temperature 0 – 40 °C
Dimensional data 2 flush mounted modules
CE certification.
Standards: IEC 60669-2-5 / EN 50491-5-2
