2120
Thermostat with display
Installer manual
Set point
The thermometer icon is not shown, and the unit of
measure of the temperature is in °C.
If the mode is set on OFF, no temperature will appear on
the display but the “- -” symbol will be displayed.
Note: you can change from °C to °F using the MyHOME_
Suite software or the user menu.
Configuration from central unit
The “CU” symbol indicates that a session with a central unit
or with a supervision software is running.
6.1 Display items
6 Programming
Temperature calibration (see paragraph 6.4).
The thermometer icon flashes quickly to indicate that
calibration is being performed.
The temperature unit is set on °C or °F depending on the
selection.
This function can be disabled using the software.
