Thermostat with display
Installer manual
Hotel thermostat
The operation in the hotel room configuration gives the customer the possibility of easily setting
the temperature to the desired level of comfort. The hotel manager can integrate the individual
thermostat installed in the room as part of a system that can be managed using a software for the
monitoring of consumptions, therefore avoiding unwanted energy waste.
Home thermostat
The third type of use, as room thermostat, manages the temperature control of an individual
system, without the need for additional control devices.
The systems consists of:
• Power supply;
• Actuators and pumps;
•
Thermostat with local contact for
the detection of open windows.
SCS
E49
PRI: 220 – 240 V~
185 – 175 mA
50/60 Hz
SCS: 27 Vdc
600 mA
230 Vac
C1 C2
ART. F430/2
1
1 2 3 4
2 43
MODE
+
–
FAN
Power supply
ThermostatActuator
Example of hotel room or individual residential system
To the
connected loads
