Bticino Sfera Series User Manual

Sfera Display Module
Installer manual
3
Contents
1 Introduction 4
1.1 Warnings and recommendations 4
2 Description 5
2.1 Front view 5
2.2 Back view 6
3 Configuration using the keypad 7
3.1 Access to the Settings menu 7
3.2 Configuration 8
3.3 LCD Setup 17
3.4 Riser base address 19
3.4 Door Codes 20
3.5 Address book – Alphanumeric mode 23
3.6 Address book – Numeric BFA mode 28
4 Configuration using the software 35
4.1 The TiSferaDesign software 35
4.2 Connection to the PC 35
5 Using the display module 36
5.1 Alphanumeric mode call 36
5.2 Numeric BFA mode call 38
5.3 Keypad module call 40
6 Appendix 41
6.1 Technical data 41

Bticino Sfera Series Specifications

General

Series	Sfera
Category	Control Unit
Storage Temperature	+70°C
Compatibility	2-wire system
Relative Humidity	95% (non-condensing)
Protection Degree	IP20
