ECM
®
830 Electroporation System
Page 16 www.btxonline.com
Quick Start (Continued)
Voltage
The Voltage indicates the set voltage in volts. The low voltage
mode range is 5 V to 500 V in 1 V increments and the high
voltage mode range is 505 V to 3000 V in 5 V increments. A
beep is heard when transitioning between LV and HV modes.
P. Length
1. Pulse Length indicates the set pulse length in µs or ms.
The pulse length minimum is 10 µs in both HV and LV
modes.
2. In the LV mode, the maximum pulse length is 10 seconds.
The pulse length units change from µs to ms at 1ms and
from ms to s at 1s.
3. Refer to Table 1 for HV pulse length maximum limits. To
estimate approximate pulse lengths at various voltages
in the high voltage mode, refer to Table 1 below.
4. Please note that the voltage determines the maximum
pulse length in the HV mode.
5. If the voltage is increased and the pre-set pulse length is
longer than the maximum pulse length allowed, the
pulse length will automatically adjust to that level.
Table 1
HV Mode
Voltage Maximum Pulse Length (µs)
505 594
750 400
1000 300
1500 200
2000 150
2500 120
3000 100
