5.6.3 PTFE filter membrane installation
b
c
filter tube
a
Fig. 5.8: Outlet fi lter membrane (PTFE) installation
• Pull out the end-cap a of the filter membrane.
• Unscrew the hose clamp b and pull off the filter membrane.
• Remove the hose clamp c from the filter tube.
➡ Gently flush the PTFE filter membrane manually only. Use standard soap detergents for cleaning.
It is recommended to exchange the filter membrane regularly.
For installation proceed in reverse order.
Wrap the end of the filter tube into the filter carrier and push in the end-cap (see Fig. 5.7).
