14 Parts lists
The following spare parts are available for Buderus
heating systems. If there are more than one Buderus
article numbers at one item number, these numbers are
listed in the columns corresponding to the various
models. In other cases the number of components is
shown.
Boiler jacket (Î Fig. 50)
Item
no.
Description Buderus
article number
Model 18
Quantity/
model
Model 25
Quantity/
model
Model 32
Quantity/
model
10 Front panel complete G124 X 63029202 1 1 1
20 Logano G124 name plate 67902838 1 1 1
30 Side panel left/right G124X 63029217 2 2 2
40 Cable holder 07060754 1 1 1
50 Cover front G124X 63035780 1 1 1
60 Cover rear 365 mm wide 63029222 1 1 1
70 Angle 3x30/20x463 complete 63012813 1 1 1
80 Rear panel complete G124 X 05078140 1 1 1
90 Boiler block insulation 6303- 5770 5771 5772
100 Clip 00476378 1 1 1
110 Sheet metal screws
Mounting
material for
boiler jacket
12 12 12
120 Angle 458X55 70001239 1 1 1
130 Cover plate 300 x 160 front cover 63016429 1 1 1
Mounting material for G124X 2 - 5 section B 05078804 1 1 1
Tab. 10 Boiler jacket

Buderus Logano G124X II/SP Specifications

General

Model	Logano G124X II/SP
Category	Boiler
Fuel Type	Gas
Heat Exchanger Material	Cast Iron
Operating Pressure	3 bar
