11
13
10
12
15
7
8
6
9
14
- 8 -
Chapter 1 Product Overview
Back Panel
6
Router button This button turns the router on and o. The operation mode is changed
by holding down the button.
7
USB LED (Blue)
On: The USB drive is connected.
Blinking: The USB drive can be removed.
Note: When this LED is blinking, the connected USB drive cannot be used. Remove the connected USB
drive. If the LED continues to blink even after the USB drive is removed, restart the AirStation. Do
not remove the USB drive or turn o the AirStation while the USB LED is on.
8
USB Eject button To dismount a USB hard drive, hold down this button until the USB LED
ashes (about 3 seconds). The USB drive can then be unplugged safely.
9
USB Port Connect the USB drive.
