Engine Air Cleaner/Filter
See
Engine Compartment Overview on page 5-10
for
the location of the engine air cleaner/filter.
When to Inspect the Engine Air
Cleaner/Filter
Inspect the air cleaner/filter every 15,000 miles
(25 000 km) and replace every 30,000 miles (50 000
km). If you are driving in dusty/dirty conditions, inspect
the filter at every oil change.
How to Inspect the Engine Air
Cleaner/Filter
To inspect the air cleaner/filter, remove the filter from
the vehicle and lightly shake the filter to release
loose dust and dirt. If the filter remains “caked” with dirt,
a new filter is required.
To inspect or replace the air cleaner/filter, do the
following:
1. Remove the two clamps on the duct.
2. Remove the duct.
3. Unlatch the two hooks on top of the engine air
cleaner/filter housing.
4. Remove and replace the engine air cleaner/filter.
5. Align the tabs located on the bottom of the
panel with the slots at the bottom of the housing.
5-17
