Halogen Bulbs
{CAUTION:
Halogen bulbs have pressurized gas inside
and can burst if you drop or scratch the bulb.
You or others could be injured. Be sure to read
and follow the instructions on the bulb
package.
Headlamps
1. Open the hood.
2. Push in on the
headlamp panel and lift
up the headlamp
retaining clip partway,
but do not remove.
3. Undo the wing stud on the upper, outboard side of
the lamp assembly.
4. Unsnap the headlamp assembly by pulling it
forward, away from the vehicle.
5. Disconnect the electrical connector by pulling back
on the locking tab, located on the electrical
connector, to separate the two connectors.
5-45
