Fuse Usage
9 ABS Solenoid Valves
10 Oxygen Sensors-Emissions Control
11 Injectors
12 Spare
13 Engine Controls
14 Daytime Running Lamps (DRL)
15 Passenger’s Low-Beam Headlamp
16 Spare
17 Driver’s Low-Beam Headlamp
18 Driver’s High-Beam Headlamp
19 Ignition Switch Battery Power
20 Parking Lamps-Front and Rear
21 Air Pump-Emissions Controls
22 Spare
23 Passenger’s High-Beam Headlamp
24 Spare
25 DVD
26 Front Fog Lamps
27
Ignition Relay, Neutral Start Switch,
Powertrain Control Module (PCM)
28 Body Control Module-Battery Power
29 Remote Digital Radio Receiver
30 All-Wheel Drive (AWD) Module
Fuse Usage
31 Cruise Control
32 Front Power Outlets/Lights, OnStar
®
33
Automatic Transaxle Shift Lock
Control System
34 Spare
35 Starter Solenoid Battery Fuse
36 ABS Motor
37 Spare
38 Spare
39 Engine Cooling Fan
40 Engine Cooling Fan
41
Main Battery Fuse for Retained
Accessory Power Relay and
Accessory Relay
42
Main Battery Fuse for Heated Seats,
Air
43 Spare
44 Spare
45
Main Battery Fuse for Power
Outlets, Level Control, Power Seats
and Mirrors and Body Computer
46 Spare
47
Main Battery Fuse for HVAC Blower
and Ignition 3 Relay
5-94
