BullFrog A7 - Home;Status Screen

16
Water Temperature
Time
Lock
Indicator
Heating Status Indicator
Desired Temperature
Adustment
Settings
Menu
Screen
Contrast
Audio
Temperature
Menu
Invert
Screen
Lighting
Menu
Jets 1
Jets 2
Wi-Fi
Indicator
Message Center
(For M9, M8, &
A9L this function
located in
Settings Menu)
Home/Status Screen
e Home/Status screen on your M Series, A Series or STIL
(A1000) control shows basic statuses including: time, jet status,
light status, screen orientation, current water temperature,
heating/cooling status, spa operation mode, audio status
(optional), day/night status, and settings. Most basic functions
of operating your spa can be performed with one touch from
the Home/Status screen. In addition, any necessary error or
maintenance messages will appear at the bottom of the screen.
Start or Stop Accessories
To start or stop an accessory (jets, lights, etc.), press the associated
button. Icons will become animated when their accessory is
turned on, and inanimate when turned o. Icons on the screen
will reect the speed or state of the devices running on your spa.
When an accessory has more than two states, press the button
once, and then again, until it reaches the desired state.
To turn on all available spa pumps in one touch press the
“Logo” button, located to the side of the main control scrreen.
Press the button again to turn o all available pumps.
Light Operation
Use the button to access the lights menu. Use the button
to turn on interior lights. Use the button to turn on exterior
lights. Use the associated menu options to control interior light
modes (ashing, fading, solid color) and/or colors.
Invert Screen Button
From the home status screen you may press the button to
rotate the screen 180 degrees for easier viewing from inside the
spa. For spa models with 3 jet pumps (M9, M8, and A9L) this
function is available in the Settings menu.
Adjusting the Set Temperature
Within 1 to 2 minutes after spa start up and initialization, the
water temperature will be displayed in the center of the home
status screen. Press the
and buttons to set the desired
temperature. e set point will appear in blue. After 3 seconds
without any change to the set temperature value, the current
water temperature will reappear in white.
When the set value is lower than the current temperature
“Cooling to xx.x” will appear at the bottom of the screen. When
the set value is higher than the current temperature, “Heating
to xx.x” will be indicated. Normally there may be a short delay
before the heating starts, during which “Heating suspended” is
indicated under the value.
Spa Settings
e settings on the M Series, A Series or STIL (A1000) control
pad are navigated by the use of the (Settings) button. One
press gives you access to several menus where you can manage the
specic settings of your spa. After pressing the Settings button
you may access a submenu by pressing the associated icon.
Note that if an accessory is not present in your spa conguration,
its menu will not appear. Refer to the following section to get
details about the possible settings, accessories, and their detailed
functionalities.
