OUTLOOK INSTALLATION
Harness Description OutLook Installation Operating Instructions Pyrometer Probe Calibration Troubleshooting
BILL OF MATERIALS
1. OutLook Monitor with Main Harness
2. OutLook Sub-harness
‘01-’05 GM, ‘03-’05 Dodge
3. Pyrometer Probe
4. Windshield Mount
5. Pillar Pod Mount
6. OBD II Connector & Harness
7. Fuse Jack
8. 90° Connector
9. Zip Ties
TOOLS NEEDED
• Flat Head Screw Driver
• Phillips Screw Driver
• Wire Strippers
• Electric Drill
• 5/16” Drill Bit
• 1/8” Pipe Tap
• 9/16” Wrench
• 5/8” Wrench
• Electrical Tape
a.
b.
a.
b.
2.
3.
1.
4.
6.
9.
5.
7.
Introduction
INTRODUCTION
You have just purchased the most technologically advanced vehicle monitor available for diesel pickups
manufactured by Bully Dog Technologies. The OutLook monitor comes with more user friendly features
than any other vehicle monitor in the market place. The OutLook monitor also comes with free technical
support, just call: 1-866-285-5936.
This instruction set outlines how to install and operate the OutLook monitor on ‘03-’07 6.0L Ford
Power Stroke, ‘03-’06 5.9L Dodge Cummins and ‘01-’06 6.6L GM Duramax diesel pickups.
