Burkert 6213 EV - Warranty; Information on the Internet; Technical Data; Operating Conditions

4
3.1 Warranty
The warranty is only valid if the device is used as intended in accordance
with the specified application conditions.
3.2 Information on the internet
The operating instructions and data sheets for type 6213 EV / 6281 EV
can be found on the internet at:
www.buerkert.com
Type “6213” or “6281”
4 TECHNICAL DATA
4.1 Operating conditions
The following values are indicated on the type label:
• Voltage (Tolerance ± 10 %) / Current type
• Coil power consumption
(active power in W - at operating temperature)
• Operating pressure
• Body material: Brass (MS), Stainless steel (VA)
• Seal material: FKM, EPDM, NBR
Circuit function:
A (NC)
2 (A)
1 (P)
2/2-way valve, normally
closed
A (NC)
2 (A)
1 (P)
2/2-way valve, normally
closed,
with manual override
B (NO)
2 (B)
1 (P)
2/2-way valve, normally
open
english
