6
The following values must also be observed for valves with
UL/UR approval:
Temperatures non-hazardous
fluids (air, water and inert gas)
-30...+120 °C
-30...+100 °C
(for 6213 EV DN40)
Ambient Temperature
-30...+55 °C
4.3 Conformity
In accordance with the EC Declaration of conformity, the solenoid
valve Type 6213 EV / 6281 EV is compliant with the EC Directives
(if applicable).
4.4 Standards
The applied standards, which verify conformity with the EC Directives,
can be found on the EC Type Examination Certificate and / or the EC
Declaration of Conformity (if applicable).
4.5 Type label (Example)
Type
Circuit function
Orifice Seal material
Body material
Identification number
Manufacturer code
Voltage, Frequency,
Power consumption
Connection thread,
operating pressure
6213EV A 10 EPDM MS
Made in Germany
W14 LU
230V 50Hz 8W
G3/8 P
N0
-
10bar
english
