11
ENG FRA ESP
DASH X FM
8NM
For initial setup, align the Mounting
Rails with position #3 on the
underside of the Bicycle Seat.
Re-attach the bolt by rotating it clockwise
to a torque value of 8NM. If you do not
have a torque wrench, please visit a bicycle
retailer to ensure proper installation.
Insert the metal Base Plate into the
slots on the underside of the Bicycle
Seat
A
, and flip it closed
B
.
5
7
6
note
See “Checking the Position of the Bicycle Seat” (Page
14) for further details.
WARNING
THIS STEP IS EXTREMELY
IMPORTANT FOR THE
SAFETY OF THE CHILD.
A
B
3
2
1
ASSEMBLY & USE
