DASH FM ASSEMBLY & USE
For initial setup, align the Mounting
Rails with position 3 on the
underside of the Bicycle Seat.
Re-attach the Mounting Knob to the bolt
on the underside of the Bicycle Seat by
rotating it clockwise
A
until tight.
Insert the metal Base Plate into the slots
on the underside of the Bicycle Seat
A
, and flip it closed
B
so that the bolt
passes through the slot in the Base Plate.
5
7
6
note
See “Checking the Position of the Bicycle Seat” for
further details.
note
During the last few rotations of the Mounting Knob,
the Locking Ring should make audible clicking noises.
When fully tightened, the Locking Ring should prevent
the Mounting Knob from rotating counter-clockwise
B
.
WARNING
THIS STEP IS EXTREMELY
IMPORTANT FOR THE
SAFETY OF THE CHILD.
3
2
1
A
A
B
B
